Product Details:
|
| MODEL NUMBER: | NL204153AC21-09 | BRAND: | NEC |
|---|---|---|---|
| SIZE: | 21.3INCH | RESOLUTION: | 2048×1536RGB |
| BRIGHTNESS: | 800CD/M2 | Lamp Type: | CCFL |
| TEMPERATURE RANGE: | Operating Temperature: 0 ~ 55 °C ; Storage Temperature: -20 ~ 60 °C | ||
| High Light: | 6 Bit NEC TFT Display,40% NTSC NEC TFT Display |
||
| Basic Information : | Brand | Model | NL204153AC21-09 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 21.3" | Alias | - | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 55 °C |
| RoHS | Vibration | 1.2G (11.76 m/s²) |
| Pixel Features : | Resolution | 2048(RGB)×1536, QXGA | Dot Pitch(mm) | 0.0705×0.2115 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.2115×0.2115 (H×V) [120PPI] | |
| Mechanical Size : | Active Area(mm) | 433.152(H) × 324.864(V) | Bezel Area(mm) | 438.2(H) × 330.0(V) |
| Outline Dim.(mm) | 457(H) × 350(V) | Depth(mm) | 34.0/37.0 (Typ./Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 4:3 (H:V) | Orientation | Landscape type | |
| Mounting : | Side mounting holes (4-M3) on left, right bezel | |||
| Other Spec : | Weight | 2.70/2.90Kgs (Typ./Max.) | Treatment | Antiglare, Hard coating (2H) |
| Basic Information : | Luminance(cd/m²) | 800 (Typ.) | Contrast Ratio | 750:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Display Mode | UA-SFT, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 14/10 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | X:0.319; Y:0.329 | Display Colors | 16.7M (8-bit) |
| Color Temperature | 6172K | White Uniformity | 1.33 (Typ.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 75% | sRGB | 100% coverage |
| Adobe RGB | 77% coverage | DCI-P3 | 78% coverage | |
| Rec.2020 | 56% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
| Signal Electrical : | Voltage Supply | 12.0V (Typ.) | Current Supply | 0.50/0.90A (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Signal Type : | LVDS (4 ch, 8-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JAE | FI-WE41P-HFE | 1 pcs | 41 pins | 1.25 mm | ||
| JAE | FI-WE31P-HFE | 1 pcs | 31 pins | 1.25 mm | ||
| JAE | IL-Z-8PL-SMTY | 1 pcs | 8 pins | 1.25 mm | ||
| Backlight Features: | Shape | Straight | Type | CCFL | Position | Direct light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | 16 pcs | Life Time | - | |
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| HRS | DF3Z-10P-2H | 1 pcs | 10 pins | 2.0 mm | ||
| JAE | IL-Z-9PL-SMTYE | 1 pcs | 9 pins | 1.25 mm | ||
| Backlight Driver : | With Inverter | |||||
| Driver Electrical : | Voltage Supply | 24.0V (Typ.) | Current Supply | 2.5/2.8/3.1A (Min./Typ./Max.) | ||
