NL192108AC21-01 NLT 18.5INCH 400CD/M2 LCM 1920×1080 1920×1080RGB WLED eDP Operating Temperature: -20 ~ 70 °C INDUSTRIAL

Large Image : NL192108AC21-01 NLT 18.5INCH 400CD/M2 LCM 1920×1080 1920×1080RGB WLED eDP Operating Temperature: -20 ~ 70 °C INDUSTRIAL

Product Details:

Place of Origin:	JAPAN
Brand Name:	NEC
Certification:	ISO9001
Model Number:	L192108AC21-01

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	120USD
Packaging Details:	STANDARD PACKING
Delivery Time:	2-3 DAYS
Payment Terms:	TT/PAYPAL/WESTERNUNION/ESCROW
Supply Ability:	200PCS

Contact Now

NL192108AC21-01 NLT 18.5INCH 400CD/M2 LCM 1920×1080 1920×1080RGB WLED eDP Operating Temperature: -20 ~ 70 °C INDUSTRIAL

Description

MODEL NUMBER:	L192108AC21-01	BRAND:	NEC
SIZE:	18.5INCH	RESOLUTION:	1920×1080RGB
BRIGHTNESS:	400CD/M2	Lamp Type:	WLED
TEMPERATURE RANGE:	Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
Highlight:	NEC TFT Display 40% NTSC , XGA 85PPI NEC TFT Display

NLT NL192108AC21-01 Overview

The NL192108AC21-01 is a 18.5 inch diagonal a-Si TFT-LCD display panel product from NLT Technologies, Ltd. (hereafter called NLT), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -30 ~ 80°C , and the maximal vibration level of 1.2G (11.76 m/s²).

NLT NL192108AC21-01 Application Details

Basic Info :	Panel Brand Panel Model NL192108AC21-01 Diagonal Size 18.5" Application Panel Type a-Si TFT-LCD , LCM Model Alias -
Reliability :	Operating Temp. -20 ~ 70 °C Storage Temp. -30 ~ 80 °C RoHS State Vibration Rating 1.2G (11.76 m/s²)
Specific Features :

NLT NL192108AC21-01 Mechanical Details

Pixel Features :	Pixel Format 1920(RGB)×1080, FHD Dot Pitch 0.071×0.213 mm (H×V) Configuration RGB Vertical Stripe Pixel Pitch 0.213×0.213 mm (H×V) [119PPI]
Mechanical Size :	Display Area 408.96×230.04 mm (H×V) Bezel Area 413.4×234.0 mm (H×V) Outline Dim. 430.4×254.6 mm (H×V) Outline Depth 13.5/14 (Typ./Max.) mm
Outline Features :	Form Factor Flat Rectangle Orientation Landscape type Aspect Ratio 16:9 (H:V) Shape Style
Holes & Brackets :	Side mounting holes (4-M3) on left, right bezel
Other Features :	Weight 1.55/1.70Kgs (Typ./Max.) Surface Antiglare, Hard coating (3H)

NLT NL192108AC21-01 Optical Details

Basic Information :	Brightness 400 cd/m² (Typ.) Contrast Ratio 1000:1 (Typ.) (Transmissive) Viewing Angle 88/88/88/88 (Typ.)(CR≥10) Optical Mode UA-SFT, Normally Black, Transmissive Viewing Direction Symmetry Response Time 12/13 (Typ.)(Tr/Td) ms
Color Performance :	Chromaticity Wx:0.313; Wy:0.329 Color Numbers 16.7M (8-bit) Color Temperature 6485K Uniformity 1.25/1.43 (Typ./Max.)(5 points)
1931 Color Gamut :	NTSC Ratio 72% sRGB 97% coverage Adobe RGB 75% coverage DCI-P3 75% coverage Rec.2020 54% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

NLT NL192108AC21-01 Interface Detail

Signal Systerm :	eDP (2 Lanes), HBR1 (2.7G/lane) Logic Voltage -
Signal Electrical :	Voltage Input 5.0V (Typ.) Current Input 420/760mA (Typ./Max.)
Interface Features :	Type Connector Position
Connector Detail :	Brand Model Pin Pitch Pins Amount Configuration I-PEX 20455-040E-02 0.5 mm 40 pins 1 pcs
