Product Details:
|
| Size: | 5.7 Inch | Screen Type: | A-Si TFT-LCD , LCM |
|---|---|---|---|
| Pixel Number: | 640(RGB)×480, VGA, 141PPI | Luminance: | 640cd/m² (Typ.) |
| Viewing Angle: | 80/80/80/80 (Typ.)(CR≥5) | Contrast Ratio: | 500 : 1 (Typ.) (TM) |
| Response: | 10/25 (Typ.)(Tr/Td) | Backlight: | WLED , 50K Hours , Without Driver |
| Signal Type: | Parallel RGB (1 Ch, 6-bit) , 33 Pins Connector | Max. Ratings: | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| Highlight: | 640cd/m² TFT LCD Pane,640x480 TFT LCD Panel,TCG057VGLCT-H51 |
||
1. HIGHEST QUALITY STANDARD DISPLAYS:
| Pixel Features : | Resolution | 640(RGB)×480, VGA | Dot Pitch(mm) | 0.060×0.180 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.180×0.180 (H×V) [141PPI] | |
| Mechanical Size : | Active Area(mm) | 115.2(H) × 86.4(V) | Bezel Area(mm) | - |
| Outline Dim.(mm) | 144(H) × 104.8(V) | Depth(mm) | 14.8±0.8 | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | - |
| Aspect Ratio | 4:3 (H:V) | Orientation | Landscape type | |
| Touch Panel : | Touch Points | - | Touch Panel | 4-wire Resistive Touch |
| TP Controller | Without touch controller | Touch Signal | - | |
| Mounting : | Rear mounting holes (4-Φ2.6) | |||
| Other Spec : | Weight | 250g (Typ.) | Treatment | Antiglare, Hard coating (2H) |
| Basic Information : | Luminance(cd/m²) | 640 (Typ.) | Contrast Ratio | 500:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥5) | Display Mode | TN, Normally White, Transmissive | |
| Best View on | - | Response(ms) | 10/25 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | X:0.320; Y:0.340 | Display Colors | 262K (6-bit) |
| Color Temperature | 6066K | White Uniformity | - | |
| 1931 Color Gamlt : | NTSC Ratio | 52% | sRGB | 72% coverage |
| Adobe RGB | 54% coverage | DCI-P3 | 54% coverage | |
| Rec.2020 | 39% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
4. Kyocera TCG057VGLCT-H51-S Interface Details:
| Signal Electrical : | Voltage Supply | 3.3V (Typ.) | Current Supply | 150/195mA (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Signal Type : | Parallel RGB (1 ch, 6-bit) | Signal Voltage | 0≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| IRISO | IMSA-9632S-33Z02-GF1 | 1 pcs | 33 pins | 0.5 mm | DRGB-33P1C6B-020A | |
