Product Details:
|
| Screen Size: | 8.0 Inch | Pixel Number: | 640(RGB)×480 (VGA) 100PPI |
|---|---|---|---|
| Active Area(mm): | 162.24 × 121.68 (H×V) | Mass: | 390±20g |
| Signal Interface: | Parallel RGB (1 Ch, 6-bit) , 32 Pins Connector | Max. Ratings: | -25 ~ 70 °C |
| Screen Type: | LCM , A-Si TFT-LCD | Arrangement: | RGB Vertical Stripe |
| Treatment: | Antiglare, Antireflection | Backlight: | 1 Pcs CCFL , 10K Hours , No Driver |
| Highlight: | 640×480 Sharp TFT LCD Display,8.0 Inch Sharp TFT LCD Display,LQ080V3DG01 |
||
LQ080V3DG01 8.0 INCH SHARP TFT-LCD 640(RGB)×480 (VGA) 100PPI PIXEL -25 ~ 70 °C Industrial LCD Panel
1. Main Information:
harp Corporation (hereafter called Sharp) LQ080V3DG01 is a 8.0 inch diagonal a-Si TFT-LCD display panel product, with an integral CCFL backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 70°C , a storage temperature range of -25 ~ 70°C , and the maximal vibration level of 2.9G (28.4 m/s²). It's general features are summarized by Panelook in the following: 3G Vibration, U/D,L/R Reverse, Matte , LAST SHIP DATE:8 July 2011. Based on its features, Panelook recommend that this model be applied to Industrial, Gaming etc.
| Screen Size : | 8.0" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
| 640(RGB)×480, VGA | RGB Vertical Stripe | 0.0845×0.2535 mm | 0.2535×0.2535 mm [100PPI] | |
| Mechanical Size : | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
| 162.24×121.68 mm | - | 183×141 mm | 14.0 (Typ.) mm | |
| Outline Features : | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
| Flat Rectangle | 4:3 | Landscape type | - | |
| Other Spec : | Mass | Panel Cover | Surface Treatment | |
| 390±20g | - | Antiglare, Antireflection | ||
| Back-light Features: | Type | Position | Life(Hours) | Amount | Shape | Replacement |
|---|---|---|---|---|---|---|
| CCFL | Edge light type | 10K(Min.) | 1 pcs | U shape | - | |
| CCFL Electrical : | Input Voltage | Input Current | Power Consumption | |||
| 770/860/950V (Min./Typ./Max.) | 4.0/6.0/7.0mA (Min./Typ./Max.) | |||||
| Operating Frequency | Startup Voltage | |||||
| 35/70KHz (Min./Max.) | 2000/2050V (Max.)(Ta=+25/-10℃) | |||||
| Interface Features : | CCFL Driver State | Physical Type | Interface Position | |||
| No | Connector | - | ||||
| Interface Detail | Brand Name | Model Name | Amount | Pins | Pin Pitch | Pin Configuration |
| JST | BHR-02(8.0)VS-1N | 1 pcs | 2 pins | 8.0 mm | BLL-2PINS-HL | |
| Signal Electrical : | Input Voltage | Input Current | Power Consumption | |||
|---|---|---|---|---|---|---|
| 3.3/5.0V (Typ.)(VCC) | 320/220mA (Typ.)(ICC) | - | ||||
| Voltage for Display Signals : | -0.3V≤VIL≤0.9V; 2.3V≤VIH≤5.5V | |||||
| Interface Features : | Signal Type | Physical Type | Interface Position | |||
| Parallel RGB (1 ch, 6-bit) | Connector | - | ||||
| Interface Detail : | Brand Name | Model Name | Amount | Pins | Pin Pitch | Pin Configuration |
| JAE | IL-FPR-32S-VF-N1 | 1 pcs | 32 pins | 0.5 mm | DRGB-32P1C6B-040A | |
5. FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
