Product Details:
|
| MODEL NUMBER: | LW550PUL-HLA1 | BRAND: | LG Display |
|---|---|---|---|
| SIZE: | 55 Inch | BRIGHTNESS: | 400CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 1920(RGBW)×1080 [FHD] 40PPI |
| VIEWING ANGLEG: | 60/60/60/60 (Min.) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 45 °C ; Storage Temperature: -20 ~ 60 °C |
| High Light: | WLED TTL Industrial Lcd Display,CCFL CSTN LCD Panel,VGA Lcd Video Panel |
||
| Basic Information : | Brand | Model | LW550PUL-HLA1 | |
|---|---|---|---|---|
| Type | OLED AM-OLED | Used For | ||
| Screen Size | 55" | Alias | LW550PUL (HL)(A1) | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 45 °C |
| Pixel Features : | Resolution | 1920(RGBW)×1080, FHD | Dot Pitch(mm) | - |
|---|---|---|---|---|
| Pixel Format | RGBW Vertical Stripe | Pixel Pitch(mm) | 0.630×0.630 (H×V) [40PPI] | |
| Mechanical Size : | Active Area(mm) | 1209.6(H) × 680.4(V) | Bezel Area(mm) | - |
| Outline Dim.(mm) | 1217.48(H) × 693.74(V) | Depth(mm) | 1.03 (Typ.) | |
| Outline Features : | Form Style | Curved Display | Outline Shape | |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | 2.40Kgs (Typ.) | Treatment | Hard coating (2H), Reflection 1.2% (Typ.) |
| Basic Information : | Luminance(cd/m²) | 400 (Typ.) | Contrast Ratio | 150000:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 60/60/60/60 (Min.) | Display Mode | - | |
| Best View on | Symmetry | Response(ms) | 1 (Typ.)(G to G); 8 (Typ.)(MPRT) | |
| Color Performance : | White Coordinate | X:0.285; Y:0.294 | Display Colors | 1.07B (10-bit) |
| Color Temperature | 9246K | White Uniformity | 1.25/1.43 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 89% | sRGB | 100% coverage |
| Adobe RGB | 86% coverage | DCI-P3 | 93% coverage | |
| Rec.2020 | 67% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Signal Electrical : | Voltage Supply | 12.0/24.0V (Typ.)(VDD/EVDD) | Current Supply | 1.61/3.23A (Typ.)(IDD/EIDD) | ||
|---|---|---|---|---|---|---|
| Consumption | 19.32/77.52W (Typ.)(PDD/EPDD) | |||||
| Signal Type : | V-by-One 8 lane | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| YEONHO | 20022WR-H14B2 | 1 pcs | 14 pins | 2.0 mm | ||
| JAE | FI-RXE51S-HF | 1 pcs | 51 pins | 0.5 mm | ||
| Package Box : | Quantity | Weight | Box Size |
|---|---|---|---|
| 70 pcs / box | - | 1440×1140×1085 mm (L×W×H) |
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
