Product Details:
|
| Model Name: | LQ042B5DG02 | Manufacturer: | Sharp |
|---|---|---|---|
| Luminance: | 350 (Typ.)(cd/m²) | Outline(mm): | 123 × 35.3 (H×V×D) |
| Screen Size: | 4.2 Inch | Backlight: | 1 Pcs CCFL |
| Pixel Number: | 400(RGB)×96 97PPI | Signal Type: | TTL |
| Screen Type: | LCM , A-Si TFT-LCD | Max. Ratings: | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
| High Light: | WLED High Brightness LCD Display,CCFL TFT LCD Screen,SVGA Sharp TFT LCD Display |
||
| Basic Information : | Luminance (cd/m²) | Viewing Angle (L/R/U/D) | Response Time (ms) |
|---|---|---|---|
| 350 (Typ.) | - | - | |
| Best View on | Display Mode | Contrast Ratio | |
| - | TN, Normally White, Transmissive | - | |
| Dispaly Color : | Color Temperature | Display Colors | White Coordinate |
| - | 262K (6-bit) | - |
| Basic Information : | Manufacturer | Panel Model | Panel Type | Alias |
|---|---|---|---|---|
| SHARP | LQ042B5DG02 | a-Si TFT-LCD , LCM | - | |
| Environment : | RoHS State | Operating Temp. | Storage Temp. | Vibration Level |
| -30 ~ 85 °C | -30 ~ 85 °C | - |
| Panel Size : | 4.2" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Format | Pixel Configuration | Pixel Pitch (mm) | Dot Pitch (mm) |
| 400(RGB)×96 | RGB Vertical Stripe | 0.261×0.261 [97PPI] | 0.087×0.261 | |
| Mechanical Size : | Active Area (mm) | Bezel Area (mm) | Outline Dimension (mm) | Outline Depth (mm) |
| 104.4(H) × 25.1(V) | - | 123(H) × 35.3(V) | 7.5 mm | |
| Outline Features : | Form Factor | Orientation | Aspect Ratio | Shape Style |
| Flat Rectangle | Landscape type | >3:1 (H:V) | ||
| Other Detail : | Weight | Panel Cover | Treatment | |
| 44.0g (Typ.) | - | - | ||
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
