Product Details:
|
| Manufacturer: | Sharp | Model Name: | LQ080M1SX01 |
|---|---|---|---|
| Pixel Number: | 1200(RGB)×1920 (WUXGA) 284PPI | Luminance: | 500 (Typ.)(cd/m²) |
| Screen Size: | 8.0 Inch | Backlight: | 5S5P WLED , 15K Hours , No Driver |
| Signal Type: | MIPI (2 Ch, 4 Data Lanes) , 51 Pins FPC | Max. Ratings: | Storage Temp.: -20 ~ 60 °C Operating Temp.: -10 ~ 50 °C |
| High Light: | CCFL Sharp TFT LCD Display,WLED LVDS TFT Touch Panel |
||
| Basic Information : | Brand | Model | Type | Model Alias |
|---|---|---|---|---|
| SHARP | LQ080M1SX01 | Oxide TFT-LCD , LCM | - | |
| Reliability : | RoHS | Operating Temperature | Storage Temperature | Vibration Resistance |
| -10 ~ 50 °C | -20 ~ 60 °C | - |
| Panel Size : | 8.0 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 1200(RGB)×1920, WUXGA | RGB Vertical Stripe | 0.0298×0.0894 mm | 0.0894×0.0894 mm [284PPI] | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 107.28×171.648 mm | - | 112.38×182.75 mm | 1.83/3.19 (Typ./Max.) mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle | 10:16 (W : H) | Portrait type | ||
| Fixation : | Without | |||
| Other Features : | Panel Cover | Weight | Surface | |
| - | 67g (Max.) | Clear, Hard coating | ||
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
|---|---|---|---|
| 500 cd/m² (Typ.) | IPS, Normally Black, Transmissive | 1500:1 (Typ.) (Transmissive) | |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed | |
| 89/89/89/89 (Typ.)(CR≥10) | Symmetry | 30 (Typ.)(Tr+Td) (ms) | |
| Dispaly Color : | Color Temperature | Color Amount | White color Chromaticity |
| 6485K | 16.7M (8-bit) | X:0.313; Y:0.329 | |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 91% | 100% | 89% | |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
| 92% | 68% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Luminance Variation : | 1.25/1.43 (Typ./Max.)(9 points) | ||
| Signal Electrical : | Current Input | Voltage Input | Consumption | |||
|---|---|---|---|---|---|---|
| 0.03/45/26/13mA (Typ.)(IDDIO/IDD/ISP/ISN) | 1.8/3.0/5.5/-5.5V (Typ.)(VDDIO/VDD/VSP/VSN) | - | ||||
| Interface Features : | Position | Type | Interface | |||
| - | FPC | MIPI (2 ch, 4 data lanes) | ||||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| 1 pcs | 0.2 mm | 51 pins | ||||
| Backlight Features: | Type | Position | Shape | Amount | Life(Hours) | Replacement |
|---|---|---|---|---|---|---|
| WLED | Edge light type | 5 strings | 5S5P | 15K(Typ.) | - | |
| WLED Electrical : | Current Input | Voltage Input | Consumption | |||
| 20mA (Typ.) | 14.5/15.0V (Typ./Max.) | 1.45/1.50W (Typ./Max.) | ||||
| Interface Features : | Position | Type | WLED Driver | |||
| - | Included in panel signal interface | No | ||||
LQ080M1SX01 supports display 1200(RGB)×1920 (WUXGA) with aspect ratio of 10:16 (W:H), whose pixels are arranged in RGB Vertical Stripe, according to calculation of Panelook it's pixel density is 284 PPI. As for mechanical detail, it features active area of 107.28(W)×171.648(H) mm, outline size of 112.38(W)×182.75(H)×3.19(D) mm, with surface treament of Clear, Hard coating, net weight of 67g (Max.). As a IPS, Normally Black, Transmissive LCM product, LQ080M1SX01 can provides 500 cd/m² display brightness 1500:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 30 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 90% (NTSC). This product adopted 5S5P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 15K hours, external backlight driver is additionally needed.
