Product Details:
|
| Manufacturer: | Sharp | Model Name: | LQ070Y5DG10 |
|---|---|---|---|
| Luminance: | 650 (Typ.)(cd/m²) | Screen Size: | 7.0 Inch |
| Backlight: | WLED | Signal Type: | CMOS (1 Ch, 6-bit) |
| Pixel Number: | 800(RGB)×480 (WVGA) 133PPI | Arrangement: | RGB Vertical Stripe |
| High Light: | CCFL Sharp TFT LCD Display,WLED LVDS TFT Touch Panel |
||
LQ070 Series LQ070Y5DG10 LQ070Y5DG09 LQ070Y5DG03 LQ070Y5DG02
| Basic Information : | Brand | SHARP | Model | LQ070Y5DG10 |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 7.0" | Alias | - |
| Pixel Features : | Resolution | 800(RGB)×480, WVGA | Dot Pitch(mm) | 0.0635×0.1905 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.1905×0.1905 (H×V) [133PPI] | |
| Mechanical Size : | Active Area(mm) | 152.4(H) × 91.44(V) | Bezel Area(mm) | - |
| Outline Dim.(mm) | 164.4(H) × 105.3(V) | Depth(mm) | 9.8 | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 15:9 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | - | Treatment | Antiglare |
| Basic Information : | Luminance(cd/m²) | 650 (Typ.) | Contrast Ratio | - |
|---|---|---|---|---|
| Viewing Angle | - | Display Mode | TN, Normally White, Transmissive | |
| Best View on | - | Response(ms) | - | |
| Color Performance : | White Coordinate | - | Display Colors | 262K (6-bit) |
