Product Details:
|
| BRAND: | Kyocera | MODEL NUMBER: | T-51440GL070H-FW-AF |
|---|---|---|---|
| SIZE: | 7INCH | RESOLUTION: | 480×234RGB |
| BRIGHTNESS: | 400 Cd/m² (Typ.) | Light Source: | CCFL [1 Pcs] , 20K Hours , With Inverter |
| Interface Type: | TFT Specific Analog RGB , 30 Pins | TEMPERATURE RANGE: | Operating Temperature: -30 ~ 75 °C |
| High Light: | CCFL CSTN LCD Panel,VGA Lcd Video Panel |
||
| Basic Information : | Manufacturer | Panel Model | Panel Type | Alias |
|---|---|---|---|---|
| T-51440GL070H-FW-AF | a-Si TFT-LCD , LCM | - | ||
| Environment : | RoHS State | Operating Temp. | Storage Temp. | Vibration Level |
| - | -30 ~ 75 °C | -40 ~ 85 °C | - | |
| Used For : |
|
|||
| Basic Information : | Luminance (cd/m²) | Viewing Angle (L/R/U/D) | Response Time (ms) |
|---|---|---|---|
| 400 (Typ.) | 60/60/30/60 (Typ.)(CR≥10) | 10/20 (Typ.)(Tr/Td) | |
| Best View on | Display Mode | Contrast Ratio | |
| 6 o'clock | TN, Normally White, Transmissive | 150 : 1 (Typ.) (Transmissive) | |
| Dispaly Color : | Color Temperature | Display Colors | White Coordinate |
| 4867K | Full color | X:0.350; Y:0.365 |
| Panel Size : | 7.0" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Format | Pixel Configuration | Pixel Pitch (mm) | Dot Pitch (mm) |
| 480(RGB)×234 | RGB Vertical Stripe | 0.321×0.372 [76PPI] | 0.107×0.372 | |
| Mechanical Size : | Active Area (mm) | Bezel Area (mm) | Outline Dimension (mm) | Outline Depth (mm) |
| 154.08(H) × 87.05(V) | - | 164.9(H) × 101.9(V) | 23.1 (Typ.) mm | |
| Outline Features : | Form Factor | Orientation | Aspect Ratio | Shape Style |
| Flat Rectangle | Landscape type | 16:9 (H:V) | ||
| Other Detail : | Weight | Panel Cover | Treatment | |
| 300g (Max.) | - | - | ||
| Reverse Scan : | Yes (U/D, L/R) |
|---|---|
| Vertical Frequency : | 60Hz |
| Time Controller (T-CON) : | Need external T-CON |
| Lamp Features: | Type | Position | Quantity | Shape | Life(Hours) | Lamp Exchange |
|---|---|---|---|---|---|---|
| CCFL | Edge light type | 1 pcs | - | 20K(Min.) | - | |
| Interface Features : | Position | Backlight Driver | Type | |||
| - | With Inverter | Included in panel signal interface | ||||
| Driver Electrical : | Voltage Supply | Current Supply | Power Consumption | |||
| 12.0V (Typ.) | - | 4.2W (Typ.) | ||||
| Panel Driving Electrical : | Voltage Supply | Current Supply | Power | |||
|---|---|---|---|---|---|---|
| 12.0V (Typ.) | - | 2.4W (Typ.) | ||||
| Detail : | Brand | Model | Pin Pitch | Pin Amount | Quantity | Configuration |
| 30 pins | 1 pcs | |||||
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
