Product Details:
|
| BRAND: | Kyocera | MODEL NUMBER: | KG057QV1CA-G05 |
|---|---|---|---|
| SIZE: | 5.7INCH | RESOLUTION: | 320×240RGB |
| BRIGHTNESS: | 220 Cd/m² (Typ.) | Signal Interface: | Parallel Data (4-bit) |
| Panel Type: | FSTN-LCD , LCM | Lamp Type: | 1 Pcs CCFL , Without Driver |
| High Light: | CCFL CSTN LCD Panel,VGA Lcd Video Panel |
||
| Basic Information : | Brand | Model | KG057QV1CA-G05 | |
|---|---|---|---|---|
| Type | LCM FSTN-LCD | Used For | ||
| Screen Size | 5.7" | Alias | - | |
| Environment : | Storage Temp. | - | Operating Temp. | - |
| RoHS | Vibration | - |
| Pixel Features : | Resolution | 320×240, QVGA | Dot Pitch(mm) | 0.360×0.360 (H×V) |
|---|---|---|---|---|
| Pixel Format | Rectangle | Pixel Pitch(mm) | 0.360×0.360 (H×V) [70PPI] | |
| Mechanical Size : | Active Area(mm) | 115.18(H) × 86.38(V) | Bezel Area(mm) | 119.4(H) × 90.6(V) |
| Outline Dim.(mm) | 144(H) × 104.8(V) | Depth(mm) | 9.0/13.2 (Typ./Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 4:3 (H:V) | Orientation | Landscape type | |
| Mounting : | Rear mounting poles (4-Φ2.6) | |||
| Other Spec : | Weight | 175g | Treatment | Glare (Haze 0%) |
| Basic Information : | Luminance(cd/m²) | 220 (Typ.) | Contrast Ratio | 40:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | - | Display Mode | STN | |
| Best View on | - | Response(ms) | 500 (Typ.)(Tr+Td) | |
| Color Performance : | White Coordinate | - | Display Colors | Monochrome |
| Frame Rate : | 75Hz |
|---|---|
| Driving Method : | Duty: 1/240 |
| Signal Type : | Parallel Data (4-bit) | Signal Voltage | ||
|---|---|---|---|---|
| Backlight Features: | Shape | - | Type | CCFL | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | 1 pcs | Life Time | - | |
| Interface Features : | Position | - | Type | Connector | ||
| Backlight Driver : | No | |||||
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
