Product Details:
|
MODEL NUMBER: | KCG057QV1DB-G52 | BRAND: | Kyocera |
---|---|---|---|
SIZE: | 5.7INCH | RESOLUTION: | 320×240RGB |
BRIGHTNESS: | 350 Cd/m² (Typ.) | Screen Type: | LCM , CSTN-LCD |
Backlight: | 1 Pcs CCFL , 75K Hours , Optional | TEMPERATURE RANGE: | Storage Temp.: -20 ~ 60 °C |
High Light: | CCFL CSTN LCD Panel,VGA Lcd Video Panel |
Basic Information : | Manufacturer | Panel Model | Panel Type | Alias |
---|---|---|---|---|
KCG057QV1DB-G52 | CSTN-LCD , LCM | - | ||
Environment : | RoHS State | Operating Temp. | Storage Temp. | Vibration Level |
0 ~ 60 °C | -20 ~ 60 °C |
Basic Information : | Luminance (cd/m²) | Viewing Angle (L/R/U/D) | Response Time (ms) |
---|---|---|---|
350 (Typ.) | 50/50/20/35 (Typ.)(CR≥2) | 180/170 (Typ.)(Tr/Td) | |
Best View on | Display Mode | Contrast Ratio | |
- | STN, Normally Black, Transmissive | 60 : 1 (Typ.) (Transmissive) | |
Dispaly Color : | Color Temperature | Display Colors | White Coordinate |
7732K | Color | X:0.300; Y:0.300 |
Panel Size : | 5.7" | |||
---|---|---|---|---|
Pixel Features : | Pixel Format | Pixel Configuration | Pixel Pitch (mm) | Dot Pitch (mm) |
320(RGB)×240 [QVGA] | RGB Vertical Stripe | 0.360×0.360 [70PPI] | 0.120×0.360 | |
Mechanical Size : | Active Area (mm) | Bezel Area (mm) | Outline Dimension (mm) | Outline Depth (mm) |
115.2(H) × 86.4(V) | 119.4(H) × 90.6(V) | 144(H) × 104.8(V) | 9.0/13.2 (Typ./Max.) mm | |
Outline Features : | Form Factor | Orientation | Aspect Ratio | Shape Style |
Flat Rectangle | Landscape type | 4:3 (H:V) | ||
Mounting : | Rear mounting poles (4-Φ2.6) | |||
Other Detail : | Weight | Panel Cover | Treatment | |
175g | - | Glare (Haze 0%) |
Reverse Scan : | No |
---|---|
Vertical Frequency : | 75Hz |
Lamp Features: | Type | Position | Quantity | Shape | Life(Hours) | Lamp Exchange |
---|---|---|---|---|---|---|
CCFL | Edge light type | 1 pcs | U shape | 75K(Typ.) | - | |
CCFL Electrical : | Voltage Supply | Current Supply | Power | |||
685V (Typ.) | 3.0/4.0/6.0mA (Min./Typ./Max.) | |||||
Operating Frequency | Kick-off Voltage | |||||
30/100KHz (Min./Max.) | 1035/1550V Max.)(Ta=+25/0℃) | |||||
Interface Features : | Position | Backlight Driver | Type | |||
- | Optional | Connector | ||||
Interface Detail : | Brand | Model | Pin Pitch | Pin Amount | Quantity | Configuration |
JST | BHR-03VS-1 | 4.0 mm | 3 pins | 1 pcs | BLL-3PINS-HNL |
Panel Driving Electrical : | Voltage Supply | Current Supply | Power | |||
---|---|---|---|---|---|---|
3.3/5.0V (Typ.)(VDD) | 40.5/27.0mA (Typ.)(3.3V/5.0V)(IDD) | - | ||||
Interface Features : | Position | Signal | Type | |||
- | Parallel Data (8-bit) | Connector | ||||
Connector Detail : | Brand | Model | Pin Pitch | Pin Amount | Quantity | Configuration |
Kyocera Elco | 08-6210-020-340-800 | 0.5 mm | 20 pins | 1 pcs |
