Product Details:
|
| Model: | LS027B7DH01 | Size: | 2.7" |
|---|---|---|---|
| Brand: | Sharp | Pixel Format: | 400×240 [WQVGA] 172PPI |
| Outline Dim.: | 62.8(H)×42.82(V) Mm | Active Area: | 58.8(H)×35.28(V) Mm |
| Viewing Angle: | 55/55/60/60 (Min.)(CR≥2) Left / Right / Up / Down | Response Time: | 10/20 (Typ.)(Tr/Td) |
| Touch Panel: | Without | Environment: | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| High Light: | CCFL LVDS Industrial LCD Panel,QVGA Sharp TFT LCD Display |
||
| Basic Information : | Brand Name | Model Name | Type | Model Alias |
|---|---|---|---|---|
| SHARP | LS027B7DH01 | CG-Silicon , LCM | - | |
| Maximum Ratings : | RoHS | Operating Temperature | Storage Temperature | Vibration Level |
| -20 ~ 70 °C | -30 ~ 80 °C | - |
| Screen Size : | 2.7" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
| 400×240, WQVGA | Rectangle | 0.147×0.147 mm | 0.147×0.147 mm [172PPI] | |
| Mechanical Size : | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
| 58.8×35.28 mm | - | 62.8×42.82 mm | 1.64 (Typ.) mm | |
| Outline Features : | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
| Flat Rectangle | 15:9 | Landscape type | ||
| Other Spec : | Mass | Panel Cover | Surface Treatment | |
| 9.90g (Typ.) | - | Hard coating (3H) | ||
| Reverse Scan : | No |
|---|---|
| Power Consumption : | 50/175uW (Typ.)(display/update) |
| Basic Information : | Luminance | Work Mode | Contrast Ratio |
|---|---|---|---|
| - | Transflective | 14:1 (Typ.) (Reflective) | |
| Good View at | Viewing Angle | Response Time | |
| - | 55/55/60/60 (Min.)(CR≥2) | 10/20 (Typ.)(Tr/Td) (ms) | |
| Dispaly Color : | Color Temperature: | Support Color | Color Coordinate |
| 6914K | Monochrome (1-bit) | X:0.305; Y:0.330 | |
| Transmissivity : | 0.25% (Typ.)(with Polarizer) | ||
| Performance : | 3D Technology | Outdoor Visibility | Reflectance |
| - | Sunlight Readable | 17.5% (Typ.) | |
| Signal Electrical : | Input Voltage | Input Current | Power Consumption | |||
|---|---|---|---|---|---|---|
| 5.0/5.0V (Typ.)(VDD/VDDA) | - | - | ||||
| Interface Features : | Signal Type | Physical Type | Interface Position | |||
| SPI | FPC | - | ||||
| Interface Detail : | Brand Name | Model Name | Amount | Pins | Pin Pitch | Pin Configuration |
| 1 pcs | 10 pins | |||||
| Package Box : | Amount | Weight | Size (L×W×H) |
|---|---|---|---|
| 400 pcs / box | - | 578×382×153 mm (L×W×H) |
LS027 Series LS027B7DH01 LS027B4DH01
