B173HAN04.0 AUO 17.3INCH 1920×1080RGB 300CD/M2 WLED eDP Operating Temp.: 0 ~ 50 °C INDUSTRIAL LCD DISPLAY

B173HAN04.0 AUO 17.3INCH 1920×1080RGB 300CD/M2 WLED eDP Operating Temp.: 0 ~ 50 °C INDUSTRIAL LCD DISPLAY
B173HAN04.0 AUO 17.3INCH 1920×1080RGB 300CD/M2 WLED eDP Operating Temp.: 0 ~ 50 °C INDUSTRIAL LCD DISPLAY B173HAN04.0 AUO 17.3INCH 1920×1080RGB 300CD/M2 WLED eDP Operating Temp.: 0 ~ 50 °C INDUSTRIAL LCD DISPLAY B173HAN04.0 AUO 17.3INCH 1920×1080RGB 300CD/M2 WLED eDP Operating Temp.: 0 ~ 50 °C INDUSTRIAL LCD DISPLAY

Large Image :  B173HAN04.0 AUO 17.3INCH 1920×1080RGB 300CD/M2 WLED eDP Operating Temp.: 0 ~ 50 °C INDUSTRIAL LCD DISPLAY

Product Details:
Place of Origin: CHINA
Brand Name: AUO
Certification: ISO9001
Model Number: B173HAN04.0
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/WESTERN UNION/ESCROW
Supply Ability: 505PCS
Contact Now

B173HAN04.0 AUO 17.3INCH 1920×1080RGB 300CD/M2 WLED eDP Operating Temp.: 0 ~ 50 °C INDUSTRIAL LCD DISPLAY

Description
MODEL NUMBER: B173HAN04.0 BRAND: AUO
SIZE: 17.3INCH RESOLUTION: 1920×1080RGB
BRIGHTNESS: 300CD/M2 TEMPERATURE RANGE: Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
High Light:

WLED LVDS AUO LCD Display

,

CCFL LVDS AUO TFT LCD



AUO B173HAN04.0 Application Details

Basic Information :
Brand

Model
B173HAN04.0
Type
a-Si TFT-LCD , LCM
Used For
  •
Screen Size
17.3 inch
Alias
AUO409D
Environment :
Storage Temp.
-20 ~ 60 °C
Operating Temp.
0 ~ 50 °C
RoHS

Vibration
1.5G (14.7 m/s²)



AUO B173HAN04.0 Mechanical Details

Pixel Features :
Resolution
1920(RGB)×1080, FHD
Dot Pitch(mm)
0.0663×0.1989 (H×V)
Pixel Format
RGB Vertical Stripe
Pixel Pitch(mm)
0.1989×0.1989 (H×V) [127PPI]
Mechanical Size :
Active Area(mm)
381.888(H) × 214.812(V)
Bezel Area(mm)
-
Outline Dim.(mm)
389.89(H) × 238.31(V)
Depth(mm)
3.3/3.5 (Typ./Max.)
Outline Features :
Form Style
Flat Rectangle
Shape Style
Flat (PCBA Flat, T3.4~4.0mm)
Aspect Ratio
16:9 (H:V)
Orientation
Landscape type
Mounting :
Without
Other Spec :
Weight
500g (Max.)
Treatment
Antiglare, Hard coating (3H)



AUO B173HAN04.0 Optical Details

Basic Information :
Luminance(cd/m²)
300 (Typ.)
Contrast Ratio
800:1 (Typ.) (Transmissive)
Viewing Angle
85/85/85/85 (Typ.)(CR≥10)
Display Mode
AHVA, Normally Black, Transmissive
Best View on
Symmetry
Response(ms)
9 (Typ.)(Tr+Td); 7 (Typ.)(G to G)
Color Performance :
White Coordinate
Wx:0.313; Wy:0.329
Display Colors
16.7M (8-bit)
Color Temperature
6485K
White Uniformity
1.25/1.60 (Max.)(5/13 points)
1931 Color Gamlt :
NTSC Ratio
71%
sRGB
94% coverage
Adobe RGB
73% coverage
DCI-P3
73% coverage
Rec.2020
53% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



AUO B173HAN04.0 Electronics Details

Frame Rate :
144Hz
Reverse Scan :
No
Total Consumption:
8.5W (Max.)



AUO B173HAN04.0 Interface Detail

Signal Electrical :
Voltage Supply
3.3V (Typ.)
Current Supply
1.42A (Max.)
Consumption
2.6/4.7W (Typ./Max.)
Signal Type :
eDP (2 Lanes), eDP1.4, HBR2 (5.4G/lane)
Logic Voltage
-
Interface Features :
Position
Right of Board
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Quantity
Pin Configuration
I-PEX
20765-040E-11A
0.5 mm
40 pins
1 pcs



AUO B173HAN04.0 Backlight Details

Backlight Features :
Type
WLED
Quantity
-
Position
Edge light type
Replacement
-
Shape
-
Life Time
15K(Min.) (Hours)
Interface Features :
Position
-
Type
Included in panel signal interface
Backlight Driver :
With LED Driver
Driver Electrical :
Voltage Supply
8.5/12.0/21.0V (Min./Typ./Max.)
Current Supply
-
Consumption
5.9W (Max.)

FAQ:

Q1: What's the quality of your LCD Panel?



A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.



Q2: What is your return and refund policy?



A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.



Q3: How long is the lead time?



A: The lead time is about 1-3 working days after receipt of payment.



Q4: How can I get the quotation?



A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
