Product Details:
|
| Size: | 5 Inch | Screen Type: | CG-Silicon, LCM |
|---|---|---|---|
| Pixel Number: | 1080(RGB)×1920 [FHD] 403PPI | Luminance: | 450cd/m² (Typ.) |
| Viewing Angle: | 80/80/80/80 (Typ.)(CR≥10) | Contrast Ratio: | 1000:1 (Typ.) (TM) |
| Response: | 35 (Max.)(Tr+Td) | Backlight: | WLED [6S2P] , W/O Driver |
| Signal Type: | MIPI (4 Data Lanes) , 40 Pins Connector | Max. Ratings: | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| Highlight: | 450cd/m² TFT LCD Display,CG Silicon TFT LCD Display,LS055T3SX05 |
||
1. HIGHEST QUALITY STANDARD DISPLAYS:
| Basic Information : | Luminance | 450 cd/m² (Typ.) | Contrast Ratio | 1000 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | Symmetry | Response Speed | 35 (Max.)(Tr+Td) (ms) | |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) | Operating Mode | New Mode2, Normally Black, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.300; Wy:0.310 | Support Color | 16.7M (8-bit) |
| Color Temperature | 7525K | White Uniformity | 1.11/1.25 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 83% | sRGB | 100% coverage |
| Adobe RGB | 80% coverage | DCI-P3 | 85% coverage | |
| Rec.2020 | 62% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Pixel Features : | Number of Pixel | 1080(RGB)×1920 [FHD] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.021×0.063 mm | Pixel Pitch(W×H) | 0.063×0.063 mm [403PPI] | |
| Physical Size : | Active Viewing | 68.04(W)×120.96(H) mm | Overall Dim. | 70.44(W)×129.59(H) mm |
| Bezel Opening | - | Overall Depth | 1.46±0.15 mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Portrait type |
| Aspect Ratio(W:H) | 9:16 | Shape Style | - | |
| Other Detail : | Mass | 27.0g (Typ.) | Surface | - |
4.Sharp LS055T3SX05 Interface Details:
| Signal Electrical : | Input Current | 10.3/7.8/5.6mA (Typ.)(IOICC/AIDD+/AIDD-) | Input Voltage | 1.8/5.0/-5.0V (Typ.)(IOVCC/AVDD+/AVDD-) | ||
|---|---|---|---|---|---|---|
| Consumption | - | Signal Interface | MIPI (4 data lanes) | |||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| Panasonic | AXE540124 | 1 pcs | 0.4 mm | 40 pins | ||
5. FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
