Product Details:
|
| Size: | 5.1 Inch | Resolution: | 240*128 |
|---|---|---|---|
| Brightness: | 150 Cd/m² (Typ.) | Viewing Angle: | 40/40/40/40 (Typ.)(CR≥2) |
| Best View On: | 6 O'clock | Display Colors: | Monochrome |
| Signal Interface: | 8-bit Parallel , 20 Pins Connector | Lamp Type: | 1 Pcs CCFL , 50K Hours , Without Driver |
| Touch Screen: | Without | Environment: | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C ; Vibration Level: 2.0G (19.6 M/s²) |
| Highlight: | 5.1 Inch Hitachi TFT Displays,240*128 Hitachi TFT Displays,LMG7420PLFC-X |
||
| Panel Size | 5.1 Inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 240×128 | Rectangle | 0.50×0.50 mm | 0.50×0.50 mm [50PPI] | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 119.97×63.97 mm | 124.0×70.0 mm | 159.4×101 mm | 12.0 (Max) mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle | 17:9 (W : H) | Landscape type | - | |
| Fixation : | Face mounting holes (4-Φ3.0) | |||
| Other Features : | Panel Cover | Weight | Surface | |
| - | 180g (Typ.) | Antiglare, Hard coating (3H) | ||
3. HITACHI LMG7420PLFC-X Optical Features:
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
|---|---|---|---|
| 150 cd/m² (Typ.) | STN, Black/White (Negative), Transmissive | 20:1 (Typ.) (Transmissive) | |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed | |
| 40/40/40/40 (Typ.)(CR≥2) | 6 o'clock | 160/110 (Typ.)(Tr/Td) (ms) | |
| Dispaly Color | Color Temperature | Color Amount | White color Chromaticity |
| - | Monochrome | - | |
| Luminance Variation : | 1.43 (Max.)(9 points | ||
4. HITACHI LMG7420PLFC-X Backlight Features:
| Backlight Features: | Type | Position | Shape | Amount | Life(Hours) | Replacement |
|---|---|---|---|---|---|---|
| CCFL | Edge light type | Straight | 1 pcs | 50K(Min.) | - | |
| CCFL Electrical : | Current Input | Voltage Input | Consumption | |||
| 2.5/5.0/5.5mA (Min./Typ./Max.) | 360V (Typ.) | |||||
| Turn-on Voltage | Lamp Frequency | |||||
| 1000V (Min.)(Ta=+25℃) | 30/70/85KHz (Min./Typ./Max.) | |||||
| Interface Features : | Position | Type | CCFL Driver | |||
| - | Connector | No | ||||
| Interface Detail | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| JAE | IL-G-4S-S3C2-SA | 1 pcs | 2.5 mm | 4 pins | BLL-4PINS-LNNH | |
5. FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours
