Product Details:
|
| Brand: | Innolux | Diagonal Size: | 5.0" |
|---|---|---|---|
| Resolution: | 640(RGB)×480, VGA 159PPI | Brightness: | 250 Cd/m² (Typ.) |
| Viewing Angle: | 70/70/50/70 (Typ.)(CR≥10) | Frequency: | 60Hz |
| Contrast Ratio: | 500:1 (Typ.) (TM) | Environment: | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| Basic Detail : | Manufacturer | Model Name | ZJ050NA-08C | |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 5.0 inch | Designed For |
|
|
| Maximum Ratings : | OP Temperature | -20 ~ 70 °C | ST Temperature | -30 ~ 80 °C |
| Basic Information : | Luminance | 250 cd/m² (Typ.) | Contrast Ratio | 500 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | 6 o'clock | Response Speed | 10/15 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.310; Wy:0.330 | Support Color | 16.7M (8-bit) |
| Color Temperature | 6638K | White Uniformity | 1.33/1.43 (Typ./Max.)(9 points) |
| Pixel Features : | Number of Pixel | 640(RGB)×480 [VGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.053×0.159 mm | Pixel Pitch(W×H) | 0.159×0.159 mm [159PPI] | |
| Physical Size : | Active Viewing | 101.76(W)×76.32(H) mm | Overall Dim. | 117.65(W)×88.43(H) mm |
| Bezel Opening | - | Overall Depth | 5.7±0.2 mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 4:3 | Shape Style | ||
| Other Detail : | Mass | 67.0g (Typ.) | Surface | Antiglare |
| Signal Electrical : | Input Current | 10/12/0.21/0.23mA (Typ.)(DIDD/AIDD/IGH/IGL) | Input Voltage | 3.3/10.4/17.0/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL) | ||
|---|---|---|---|---|---|---|
| Consumption | 0.2W (Typ.) | Signal Interface | Parallel RGB (1 ch, 8-bit) | |||
| Logic Voltage for Signals : | 0≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD | |||||
| Interface Features : | Position | - | Physical Type | FPC | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| 1 pcs | 0.5 mm | 50 pins | ||||
| Lamp Features: | Lamp Shape | - | Lamp Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Exchange | - | Amount | - | Life | 15K(Min.) (Hours) | |
| Lamp Electrical : | Input Current | 60/80mA (Typ./Max.) | Input Voltage | 14.5/16/17.5V (Min./Typ./Max.) | ||
| Consumption | 0.96W (Typ.) | |||||
| Interface Features : | Position | - | Physical Type | Included in signal interface | ||
| Backlight Driver : | No | |||||
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 101.76(W)×76.32(H) mm, outline size of 117.65(W)×88.43(H)×5.9(D) mm, with surface treament of Antiglare, net weight of 67.0g (Typ.). As a TN, Normally White, Transmissive LCM product, ZJ050NA-08C can provides 250 cd/m² display brightness 500:1 transimissive contrast ratio, 70/70/50/70 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 10/15 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 50% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 15K hours, external backlight driver is additionally needed. ZJ050NA-08C utilizes Parallel RGB (1 ch, 8-bit) as it's signal inputting systerm, which connected by 50 pins FPC with power supply voltage of 3.3/10.4/17.0/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL)
