Product Details:
|
| MODEL NUMBER: | LD230EKS-FPN1 | BRAND: | LG DISPLAY |
|---|---|---|---|
| SIZE: | 23.1INCH | BRIGHTNESS: | 700CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 1920×158(RGB), 83PPI |
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | Light Source: | WLED , 50K Hours |
| Highlight: | 83PPI TFT LCD Panel,TFT LCD Panel 700cd/m2,LD230EKS-FPN1 Square Tft Panel |
||
| Basic Information : | Brand | Model | Type | Model Alias |
|---|---|---|---|---|
| LD230EKS-FPN1 | a-Si TFT-LCD , LCM | - | ||
| Reliability : | RoHS | Operating Temperature | Storage Temperature | Vibration Resistance |
| 0 ~ 45 °C | -20 ~ 60 °C |
| Panel Size : | 23.1 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 1920×158(RGB) | RGB Horizontal Stripe | 0.305×0.102 mm | 0.305×0.305 mm [83PPI] | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 585.56×48.18 mm | - | 593.8×63.4 mm | 19.6 (Typ.) mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle | >3:1 (W : H) | Landscape / Portrait | ||
| Touchscreen : | Touch Points | TP Controller | Signal Type | Touch Tech |
| - | - | - | In-Cell Touch | |
| Fixation : | Side mounting holes (10 pcs) on up, down bezel | |||
| Other Features : | Panel Cover | Weight | Surface | |
| - | 820g (Typ.) | Antiglare, Hard coating (4H) | ||
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
|---|---|---|---|
| 700 cd/m² (Typ.) | IPS, Normally Black, Transmissive | - | |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed | |
| 89/89/89/89 (Min.)(CR≥10) | Symmetry | - | |
| Dispaly Color : | Color Temperature | Color Amount | White color Chromaticity |
| - | 16.7M (8-bit) | - | |
| Performance : | 3D Type | Outdoor Visibility | Reflectance |
| - | Sunlight Readable |
| Backlight Features: | Type | Position | Shape | Amount | Life(Hours) | Replacement |
|---|---|---|---|---|---|---|
| WLED | Edge light type | - | - | 50K(Typ.) |
| Package Carton : | Amount | Weight | Carton Size |
|---|---|---|---|
| 6 pcs / box | 6.70 Kgs | 660×210×219 mm (L×W×H) |
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
