Product Details:
|
| MODEL NUMBER: | LM190E05-SL02 | VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) |
|---|---|---|---|
| RESOLUTION: | 1280(RGB)×1024 (SXGA) 86PPI | Lamp Type: | WLED |
| BRIGHTNESS: | 280CD/M2 | SIZE: | 19.0 Inch |
| BRAND: | LG DISPLAY | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| High Light: | LM190E05-SL02 Lcd Video Module,WVGA Industrial TFT Display,280cd/m2 Lcd Video Display |
||
| Basic Information : | Brand | Model | LM190E05-SL02 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 19.0" | Alias | LM190E05 (SL)(02) | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 50 °C |
| Pixel Features : | Resolution | 1280(RGB)×1024, SXGA | Dot Pitch(mm) | 0.098×0.294 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.294×0.294 (H×V) [86PPI] | |
| Mechanical Size : | Active Area(mm) | 376.32(H) × 301.056(V) | Bezel Area(mm) | 380.3(H) × 305.0(V) |
| Outline Dim.(mm) | 396(H) × 324(V) | Depth(mm) | 16.5/20.5 (Typ./Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | Normal bezel |
| Aspect Ratio | 5:4 (H:V) | Orientation | Landscape type | |
| Mounting : | Side mounting holes (4-M3) on left, right bezel | |||
| Other Spec : | Weight | 2.97/3.12Kgs (Typ./Max.) | Treatment | Antiglare, Hard coating (3H) |
| Basic Information : | Luminance(cd/m²) | 280 (Typ.) | Contrast Ratio | 600:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | IPS, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 7/11 (Typ.)(Tr/Td); 14 (Typ.)(G to G) | |
| Color Performance : | White Coordinate | X:0.313; Y:0.329 | Display Colors | 16.7M (8-bit) |
| Color Temperature | 6485K | White Uniformity | 1.33 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 71% | sRGB | 93% coverage |
| Adobe RGB | 74% coverage | DCI-P3 | 74% coverage | |
| Rec.2020 | 53% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Signal Electrical : | Voltage Supply | 12.0V (Typ.) | Current Supply | 0.46/0.53A (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Consumption | 5.5/7.0W (Typ./Max.) | |||||
| Signal Type : | LVDS (2 ch, 8-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| LS Mtron | GT101-30S-H16 | 1 pcs | 30 pins | 1.0 mm | LVDS-30P2C8B-160A | |
| Backlight Features: | Shape | Straight | Type | CCFL | Position | Edge light type (Top and Bottom) |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | 6 pcs | Life Time | 45K(Min.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 655/675/790V (Min./Typ./Max.) | Current Supply | 3.0/7.0/7.5mA (Min./Typ./Max.) | ||
| Frequency | 40/60/70KHz (Min./Typ./Max.) | Startup Voltage | 1100/1400V (Max.)(Ta=+25/0℃) | |||
| Consumption | 28.35/31.19W (Typ./Max.) | |||||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| AMP | 1674817-1 | 2 pcs | 2 pins | 3.5 mm | BLL-2PINS-HL | |
| JST | BHR-05VS-1 | 2 pcs | 5 pins | 4.0 mm | BLL-5PINS-HHNLL | |
| Backlight Driver : | No | |||||
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
