Product Details:
|
MODEL NUMBER: | LC550EGG-FLM1 | BRAND: | LG DISPLAY |
---|---|---|---|
SIZE: | 55 Inch | BRIGHTNESS: | 500CD/M2 |
Lamp Type: | WLED | RESOLUTION: | 3840(3)×2160 [UHD] 80PPI |
VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
High Light: | 3840x2160 Square Tft Screen,Square Tft Screen 500cd/m2,80PPI TFT LCD Panel |
Basic Information : | Brand Name | Model Name | Type | Model Alias |
---|---|---|---|---|
LC550EGG-FLM1 | a-Si TFT-LCD , LCM | LC550EGG (FL)(M1) | ||
Maximum Ratings : | RoHS | Operating Temperature | Storage Temperature | Vibration Level |
0 ~ 50 °C | -20 ~ 60 °C |
Screen Size : | 55" | |||
---|---|---|---|---|
Pixel Features : | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
3840(3)×2160, UHD | RGBW Vertical Stripe | - | 0.315×0.315 mm [80PPI] | |
Mechanical Size : | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
1209.6×680.4 mm | 1213.6×684.9 mm | 1236.92×712.51 mm | 25.71 (Typ.) mm | |
Outline Features : | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
Flat Rectangle | 16:9 | Landscape type | ||
Other Spec : | Mass | Panel Cover | Surface Treatment | |
12.0/12.6Kgs (Typ./Max.) | - | Antiglare (Haze 3%), Hard coating (2H) |
Basic Information : | Luminance | Work Mode | Contrast Ratio |
---|---|---|---|
500 cd/m² (Typ.) | IPS, Normally Black, Transmissive | 1200:1 (Typ.) (Transmissive) | |
Good View at | Viewing Angle | Response Time | |
Symmetry | 89/89/89/89 (Min.)(CR≥10) | 8/10 (Typ.)(Tr/Td) (ms) | |
Dispaly Color : | Color Temperature: | Support Color | Color Coordinate |
9966K | 1.07B (8-bit + Dithering) | X:0.281; Y:0.288 | |
1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
76% | 99% | 77% | |
DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
79% | 57% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
White Uniformity : | 1.54 (Max.)(9 points) |
Back-light Features: | Type | Position | Life(Hours) | Amount | Shape | Replacement |
---|---|---|---|---|---|---|
WLED | Edge light type | 30K(Min.) | - | - | - | |
WLED Electrical : | Input Voltage | Input Current | Power Consumption | |||
106.6±7.2V | 110±5.5mA (Typ.) | 70.3/75.1W (Typ./Max.) | ||||
Interface Features : | WLED Driver State | Physical Type | Interface Position | |||
No | Connector | - | ||||
Interface Detail | Brand Name | Model Name | Amount | Pins | Pin Pitch | Pin Configuration |
UJU | HS100-L08N-N62 | 1 pcs | 8 pins | 1.0 mm | BLE-8PINS-CCCNNNNA | |
UJU | HS100-L08N-N62-A | 1 pcs | 8 pins | 1.0 mm | BLE-8PINS-ANNNNCCC |
Signal Electrical : | Input Voltage | Input Current | Power Consumption | |||
---|---|---|---|---|---|---|
12.7V (Typ.)(VLCD) | 0.85/1.11A (Typ./Max.) | 10.8/14.04W (Typ./Max.) | ||||
Interface Features : | Signal Type | Physical Type | Interface Position | |||
EPI | Connector | - | ||||
Interface Detail : | Brand Name | Model Name | Amount | Pins | Pin Pitch | Pin Configuration |
HRS | TF06L-60S-0.5SH | 2 pcs | 60 pins | 0.5 mm |
Package Box : | Amount | Weight | Size (L×W×H) |
---|---|---|---|
18 pcs / box | - | 1440×1140×960 mm (L×W×H) |
