20.0" 1600×900 250cd/M2 square Tft Display LM200WD3-TLF1

20.0" 1600×900 250cd/M2 square Tft Display LM200WD3-TLF1
20.0" 1600×900 250cd/M2 square Tft Display LM200WD3-TLF1 20.0" 1600×900 250cd/M2 square Tft Display LM200WD3-TLF1 20.0" 1600×900 250cd/M2 square Tft Display LM200WD3-TLF1 20.0" 1600×900 250cd/M2 square Tft Display LM200WD3-TLF1 20.0" 1600×900 250cd/M2 square Tft Display LM200WD3-TLF1

Large Image :  20.0" 1600×900 250cd/M2 square Tft Display LM200WD3-TLF1

Product Details:
Place of Origin: JAPAN
Brand Name: LG.Philips LCD
Certification: ISO9001
Model Number: LM200WD3-TLF1
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 160PCS
Contact Now

20.0" 1600×900 250cd/M2 square Tft Display LM200WD3-TLF1

Description
MODEL NUMBER: LM200WD3-TLF1 BRAND: LG.Philips LCD
SIZE: 20.0INCH BRIGHTNESS: 250CD/M2
Lamp Type: WLED RESOLUTION: 1600(RGB)×900 [HD+] 91PPI
VIEWING ANGLEG: 85/85/75/85 (Typ.)(CR≥10) TEMPERATURE RANGE: Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
High Light:

1600x900 Square Tft Display

,

250cd/M2 Square Tft Display

,

20.0" Lcd Video Module

LG.Philips LCD LM200WD3-TLF1 Application Details

Basic Info :
Panel Brand

LM200WD3-TLF1Panel Model
Diagonal Size
20.0"
Application

a-Si TFT-LCD , LCMPanel Type
Model Alias
LM200WD3 (TL)(F1)
Reliability :
Operating Temp.
0 ~ 50 °C
Storage Temp.
-20 ~ 60 °C



LG.Philips LCD LM200WD3-TLF1 Mechanical Details

Pixel Features :
Pixel Format
1600(RGB)×900, HD+
Dot Pitch
0.09225×0.27675 mm (H×V)
Configuration
RGB Vertical Stripe
Pixel Pitch
0.27675×0.27675 mm (H×V) [91PPI]
Mechanical Size :
Display Area
442.8×249.075 mm (H×V)
Bezel Area
446.8×253.1 mm (H×V)
Outline Dim.
462.8×272 mm (H×V)
Outline Depth
10.2 (Typ.) mm
Outline Features :
Form Factor
Flat Rectangle
Orientation
Landscape type
Aspect Ratio
16:9 (H:V)
Shape Style
Normal bezel
Holes & Brackets :
Side mounting holes (4-M3) on left & right side
Other Features :
Weight
1.49/1.50Kgs (Typ./Max.)
Surface
Antiglare, Hard coating (3H)



LG.Philips LCD LM200WD3-TLF1 Optical Details

Basic Information :
Brightness
250 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (Transmissive)
Viewing Angle
85/85/75/85 (Typ.)(CR≥10)
Optical Mode
TN, Normally White, Transmissive
Viewing Direction
6 o'clock
Response Time
1.3/3.7 (Typ.)(Tr/Td) ms
Color Performance :
Chromaticity
Wx:0.313; Wy:0.329
Color Numbers
16.7M (6-bit + Hi-FRC)
Color Temperature
6485K
Uniformity
1.33 (Max.)(9 points)
1931 Color Gamlt :
NTSC Ratio
72%
sRGB
98% coverage
Adobe RGB
76% coverage
DCI-P3
75% coverage
Rec.2020
54% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



LG.Philips LCD LM200WD3-TLF1 Backlight Details

Back-light Features :
Lamp Type
WLED
Amount
13S2P
Life Time
30K(Min.) (Hours)
Replacement
-
Lamp Shape
2 strings
Position
Edge light type (Right side)
Lamp Electrical :
Voltage Input
41.6±2.6V
Current Input
120/125mA (Typ./Max.)
Consumption
9.8/10.5W (Typ./Max.)
Interface Features :
Type
Connector
Position

NoLamp Driver
Interface Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration
JST
SM06B-SHJH(HF)
1.0 mm
6 pins
1 pcs
BLE-6PINS-CNAANC



LG.Philips LCD LM200WD3-TLF1 Interface Detail

Signal Systerm :
LVDS (2 ch, 8-bit)
Logic Voltage
-
Signal Electrical :
Voltage Input
5.0V (Typ.)
Current Input
700/875mA (Typ./Max.)
Consumption
3.0/3.8W (Typ./Max.)
Interface Features :
Type
Connector
Position
Connector Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration
LS Mtron
GT103-30S-HF15-E2500
1.0 mm
30 pins
1 pcs
LVDS-30P2C8B-160C



LG.Philips LCD LM200WD3-TLF1 Carton Details

Package Carton : Amount Net Weight Carton Size (L×W×H)
12 pcs / box - 355×305×560 mm



FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
