Product Details:
|
| MODEL NUMBER: | LM201W01-SLA3 | BRAND: | LG. LCD |
|---|---|---|---|
| SIZE: | 20.1INCH | Signal Interface: | LVDS |
| Lamp Type: | WLED | RESOLUTION: | 1680(RGB)×1050 (WSXGA+) 98PPI |
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| High Light: | IPS Lcd Display Panels,NTSC Lcd Video Panel,Antiglare NEC TFT Display |
||
| Basic Detail : | Manufacturer | Model Name | LM201W01-SLA3 | |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | LM201W01 (SL)(A3) | |
| Panel Size | 20.1 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | 0 ~ 50 °C | ST Temperature | -20 ~ 60 °C |
| Basic Information : | Luminance | - | Contrast Ratio | - |
|---|---|---|---|---|
| Good View at | Symmetry | Response Speed | - | |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Operating Mode | S-IPS, Normally Black, Transmissive | |
| Color Performance : | Chromaticity | - | Support Color | 16.7M (8-bit) |
| Pixel Features : | Number of Pixel | 1680(RGB)×1050 [WSXGA+] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.086×0.258 mm | Pixel Pitch(W×H) | 0.258×0.258 mm [98PPI] | |
| Physical Size : | Active Viewing | 433.44(W)×270.9(H) mm | Overall Dim. | - |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 16:10 | Shape Style | Normal bezel |
| Refresh Rate : | 60Hz |
|---|
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 433.44(W)×270.9(H) mm. As a S-IPS, Normally Black, Transmissive LCM product, LM201W01-SLA3 can provides , 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry . Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product adopted 6 pcs CCFL as it's backlight systerm. It's typical vertical frame rate (Fv) is 60Hz. For more latest product detail of LM201W01-SLA3 We strongly recommend that you should refer to datasheet listed on Panelook.com or contact with LG. LCD or it's distributor. The above parameters are not from the datasheet, only as a reference, please use with caution!
