Product Details:
|
| MODEL NUMBER: | LC600EQF-PHF1 | BRAND: | LG Display |
|---|---|---|---|
| SIZE: | 60.0INCH | BRIGHTNESS: | 450CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 3840(RGB)×2160 (UHD) 74PPI |
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| High Light: | IPS Lcd Display Panels,NTSC Lcd Video Panel,Antiglare NEC TFT Display |
||
| Basic Information : | Brand | Model | LC600EQF-PHF1 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 60" | Alias | LC600EQF (PH)(F1) | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 50 °C |
| Pixel Features : | Resolution | 3840(RGB)×2160, UHD | Dot Pitch(mm) | 0.11435×0.34305 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.34305×0.34305 (H×V) [74PPI] | |
| Mechanical Size : | Active Area(mm) | 1317.31(H) × 740.988(V) | Bezel Area(mm) | - |
| Outline Dim.(mm) | 1333.8(H) × 764.7(V) | Depth(mm) | 12.4/28.3 (Typ./Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | 17.1/17.9Kgs (Typ./Max.) | Treatment | Antiglare (Haze 1%), Hard coating (2H) |
| Basic Information : | Luminance(cd/m²) | 450 (Typ.) | Contrast Ratio | 1200:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Display Mode | IPS, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 5 (Typ.)(G to G); 8 (Typ.)(MPRT) | |
| Color Performance : | White Coordinate | X:0.281; Y:0.288 | Display Colors | 16.7M/1.07B (8-bit / 10-bit) |
| Color Temperature | 9966K | White Uniformity | 1.43/1.54 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 70% | sRGB | 96% coverage |
| Adobe RGB | 73% coverage | DCI-P3 | 73% coverage | |
| Rec.2020 | 52% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Signal Electrical : | Voltage Supply | 12.0V (Typ.) | Current Supply | 0.86/1.12A (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Consumption | 10.32/13.42W (Typ./Max.) | |||||
| Signal Type : | V-by-One 16 lane | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| 2037WR-H05 | 1 pcs | 5 pins | ||||
| JAE | FI-RE51S-HF | 1 pcs | 51 pins | 0.5 mm | ||
| JAE | FI-RE41S-HF | 1 pcs | 41 pins | 0.5 mm | ||
| Backlight Features: | Shape | - | Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | - | Life Time | 30K(Min.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 80.1±5.2V | Current Supply | 180±9mA | ||
| Consumption | 86.5/92.1W (Typ./Max.) | |||||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| UJU | HS100-L08N-N62 | 1 pcs | 8 pins | 1.0 mm | BLE-8PINS-CCCNNNNA | |
| UJU | HS100-L08N-N62-A | 1 pcs | 8 pins | 1.0 mm | BLE-8PINS-ANNNNCCC | |
| Backlight Driver : | No | |||||
| Package Box : | Quantity | Weight | Box Size |
|---|---|---|---|
| 18 pcs / box | - | 1600×1140×1053 mm (L×W×H) |
