Product Details:
|
| MODEL NUMBER: | ZJ090NA-03C | BRAND: | INNOLUX |
|---|---|---|---|
| SIZE: | 9.0INCH | BRIGHTNESS: | 250CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 800(RGB)×480, WVGA, 104PPI |
| VIEWING ANGLEG: | 70/70/50/70 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temp.: -20 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| High Light: | VGA Lcd Video Panel,WVGA Industrial TFT Display,WVGA TFT LCD Panel |
||
| Basic Info : | Panel Brand | Panel Model | ZJ090NA-03C | |
|---|---|---|---|---|
| Diagonal Size | 9.0" | Application | ||
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | - | |
| Reliability : | Operating Temp. | -20 ~ 80 °C | Storage Temp. | -30 ~ 80 °C |
| Pixel Features : | Pixel Format | 800(RGB)×480 [WVGA] | Dot Pitch | 0.0825×0.2327 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.2475×0.2327 mm (H×V) [104PPI] | |
| Mechanical Size : | Display Area | 198×111.696 mm (H×V) | Bezel Area | 201.0×114.7 mm (H×V) |
| Outline Dim. | 211.1×126.5 mm (H×V) | Outline Depth | 5.9±0.3 mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 16:9 (H:V) | Shape Style | ||
| Other Features : | Weight | 253g (Typ.) | Surface | Antiglare |
| Basic Information : | Brightness | 250 cd/m² (Typ.) | Contrast Ratio | 500:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) | Optical Mode | TN, Normally White, Transmissive | |
| Viewing Direction | 6 o'clock | Response Time | 10/15 (Typ.)(Tr/Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.310; Wy:0.330 | Color Numbers | 16.7M (8-bit) |
| Color Temperature | 6638K | White Uniformity | 1.33/1.43 (Typ./Max.)(9 points) |
| Frame Frequency : | 60Hz |
|---|---|
| Reverse Scan : | Yes (U/D, L/R) |
| Power Consumption : | 5.01W (Typ.) |
| Time Controller (T-CON) : | Embedded T-CON |
| Back-light Features: | Lamp Shape | Array | Lamp Type | WLED | Life Time | 20K(Min.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | 3S11P | Position | Edge light type | |
| Lamp Electrical : | Voltage Input | 9.6V (Typ.) | Current Input | 220±22mA | ||
| Consumption | 2.05W (Typ.) | |||||
| Interface Features : | Type | Included in panel signal interface | Position | - | Lamp Driver | No |
| Signal Systerm : | Parallel RGB (1 ch, 8-bit) | Logic Voltage | 0≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 3.3/10.4/17.0/-5.0V (Typ.)(DVDD/AVDD/VGH/VGL) | Current Input | 5.5/32/0.3/0.3mA (Typ.)(DIDD/AIDD/IGH/IGL) | ||
| Consumption | 0.36W (Typ.) | |||||
| Interface Features : | Type | FPC | Position | - | ||
| FPC Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| 0.5 mm | 50 pins | 1 pcs | ||||
| Package Carton : | Amount | Net Weight | Carton Size (L×W×H) |
|---|---|---|---|
| 30 pcs / box | 10.45±0.53 Kgs | 530×355×255 mm |
