ZJ027NA-02P Innolux 2.7" 320(RGB)×240 315 cd/m² INDUSTRIAL LCD DISPLAY

ZJ027NA-02P Innolux 2.7" 320(RGB)×240 315 cd/m² INDUSTRIAL LCD DISPLAY
ZJ027NA-02P Innolux 2.7" 320(RGB)×240 315 cd/m² INDUSTRIAL LCD DISPLAY ZJ027NA-02P Innolux 2.7" 320(RGB)×240 315 cd/m² INDUSTRIAL LCD DISPLAY ZJ027NA-02P Innolux 2.7" 320(RGB)×240 315 cd/m² INDUSTRIAL LCD DISPLAY

Large Image :  ZJ027NA-02P Innolux 2.7" 320(RGB)×240 315 cd/m² INDUSTRIAL LCD DISPLAY

Product Details:
Place of Origin: JAPAN
Brand Name: INNOLUX
Certification: ISO9001
Model Number: ZJ027NA-02P
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 10000PCS

ZJ027NA-02P Innolux 2.7" 320(RGB)×240 315 cd/m² INDUSTRIAL LCD DISPLAY

Description
MODEL NUMBER: ZJ027NA-02P BRAND: INNOLUX
SIZE: 2.7INCH BRIGHTNESS: 315CD/M2
Lamp Type: WLED RESOLUTION: 320(RGB)×240 [QVGA] 150PPI
VIEWING ANGLEG: 60/60/50/55 (Typ.)(CR≥10) TEMPERATURE RANGE: Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C
High Light:

VGA Lcd Video Panel

,

WVGA Industrial TFT Display

,

WVGA TFT LCD Panel

Innolux ZJ027NA-02P Application Details

Basic Detail : Manufacturer   Model Name ZJ027NA-02P
Panel Type a-Si TFT-LCD , LCM Another Name -
Panel Size 2.7 inch Designed For




  •
Maximum Ratings : OP Temperature -20 ~ 70 °C ST Temperature -30 ~ 80 °C



Innolux ZJ027NA-02P Optical Details

Basic Information : Luminance 315 cd/m² (Typ.) Contrast Ratio 300 : 1 (Typ.) (Transmissive)
Good View at - Response Speed 15/20 (Typ.)(Tr/Td) (ms)
Viewing Angle 60/60/50/55 (Typ.)(CR≥10)  Operating Mode TN, Normally White, Transmissive
Color Performance : Chromaticity Wx:0.295; Wy:0.335 Support Color 16.7M (8-bit)
Color Temperature 7424K White Uniformity -



Innolux ZJ027NA-02P Mechanical Details

Pixel Features : Number of Pixel 320(RGB)×240 [QVGA] Arrangement RGB Delta
Dot Pitch(W×H) 0.05625×0.16875 mm Pixel Pitch(W×H) 0.16875×0.16875 mm [150PPI]
Physical Size : Active Viewing 54(W)×40.5(H) mm Overall Dim. 63.5(W)×46.6(H) mm
Bezel Opening 56.6(W)×43.1(H) mm Overall Depth 2.5±0.2 mm
Outline Features : Form Shape Flat Rectangle Orientation Landscape type
Aspect Ratio(W:H) 4:3 Shape Style
Other Detail : Mass 15.7g (Typ.) Surface Antiglare

Innolux ZJ027NA-02P Interface Details

Signal Electrical : Input Current - Input Voltage 3.3V (Typ.)
Consumption 30mW (Typ.) Signal Interface Serial RGB (8-bit) + SPI
Interface Features : Position - Physical Type FPC
Signal Interface : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
    1 pcs 0.5 mm 41 pins



Innolux ZJ027NA-02P Lightting Details

Lamp Features: Lamp Shape 1 string Lamp Type WLED Position Edge light type
Exchange - Amount 2S1P Life -
Lamp Electrical : Input Current 25/27mA (Typ./Max.) Input Voltage 6.4/7.0V (Typ./Max.)
Consumption 165/194mW (Typ./Max.)
Interface Features : Position - Physical Type Included in panel signal interface
Backlight Driver : No



Innolux ZJ027NA-02P Electronics Details

Refresh Rate : 60Hz
Reverse Scan : No
