P070ACG-AZ1 Innolux 7.0" 600(RGB)×1024 350 cd/m² INDUSTRIAL LCD DISPLAY

P070ACG-AZ1 Innolux 7.0" 600(RGB)×1024 350 cd/m² INDUSTRIAL LCD DISPLAY
P070ACG-AZ1 Innolux 7.0" 600(RGB)×1024 350 cd/m² INDUSTRIAL LCD DISPLAY P070ACG-AZ1 Innolux 7.0" 600(RGB)×1024 350 cd/m² INDUSTRIAL LCD DISPLAY P070ACG-AZ1 Innolux 7.0" 600(RGB)×1024 350 cd/m² INDUSTRIAL LCD DISPLAY

Large Image :  P070ACG-AZ1 Innolux 7.0" 600(RGB)×1024 350 cd/m² INDUSTRIAL LCD DISPLAY

Product Details:
Place of Origin: JAPAN
Brand Name: INNOLUX
Certification: ISO9001
Model Number: P070ACG-AZ1
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 100PCS
Contact Now

P070ACG-AZ1 Innolux 7.0" 600(RGB)×1024 350 cd/m² INDUSTRIAL LCD DISPLAY

Description
MODEL NUMBER: P070ACG-AZ1 BRAND: INNOLUX
SIZE: 7.0INCH BRIGHTNESS: 350CD/M2
Lamp Type: WLED RESOLUTION: 600(RGB)×1024 [WSVGA] 170PPI
VIEWING ANGLEG: 85/85/85/85 (Typ.)(CR≥10) TEMPERATURE RANGE: Operating Temperature: -10 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
High Light:

VGA Lcd Video Panel

,

WVGA Industrial TFT Display

,

WVGA TFT LCD Panel



Innolux P070ACG-AZ1 Application Details

Basic Info :
Panel Brand

P070ACG-AZ1Panel Model
Diagonal Size
7.0"
Application

a-Si TFT-LCD , LCMPanel Type
Model Alias
-
Reliability :
Operating Temp.
-10 ~ 50 °C
Storage Temp.
-20 ~ 60 °C



Innolux P070ACG-AZ1 Mechanical Details

Pixel Features :
Pixel Format
600(RGB)×1024, WSVGA
Dot Pitch
0.0496×0.1488 mm (H×V)
Configuration
RGB Vertical Stripe
Pixel Pitch
0.1488×0.1488 mm (H×V) [170PPI]
Mechanical Size :
Display Area
89.28×152.37 mm (H×V)
Bezel Area
-
Outline Dim.
95×163.3 mm (H×V)
Outline Depth
2.4/4.5 (Typ./Max.) mm
Outline Features :
Form Factor
Flat Rectangle
Orientation
Portrait type
Aspect Ratio
10:17 (H:V)
Shape Style

Holes & Brackets :
Without
Other Features :
Weight
TBD
Surface
Hard coating



Innolux P070ACG-AZ1 Optical Details

Basic Information :
Brightness
350 cd/m² (Typ.)
Contrast Ratio
800:1 (Typ.) (Transmissive)
Viewing Angle
85/85/85/85 (Typ.)(CR≥10)
Optical Mode
IPS, Normally Black, Transmissive
Viewing Direction
Symmetry
Response Time
10/15 (Typ.)(Tr/Td) ms
Color Performance :
Chromaticity
Wx:0.310; Wy:0.330
Color Numbers
16.7M (8-bit)
Color Temperature
6638K
Uniformity
1.33/1.43 (Typ./Max.)(9 points)



Innolux P070ACG-AZ1 Backlight Details

Back-light Features :
Lamp Type
WLED
Amount
-
Life Time
15K(Min.) (Hours)
Replacement
-
Lamp Shape
Array
Position
Edge light type
Lamp Electrical :
Voltage Input
8.7/9.0V (Typ./Max.)
Current Input
120/125mA (Typ./Max.)
Interface Features :
Type
Included in panel signal interface
Position
-
Lamp Driver
No



Innolux P070ACG-AZ1 Interface Detail

Signal Systerm :
MIPI (4 data lanes)
Logic Voltage
-
Signal Electrical :
Voltage Input
3.3/10.0/21.0/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL)
Current Input
TBD
Consumption
TBD
Interface Features :
Type
Connector
Position
-
Connector Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration
HRS
FH12A-40S-0.5SH
0.5 mm
40 pins
1 pcs




FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
