250cd/M2 23.6in 92PPI Square Tft Display M238HCA-L3B Innolux

250cd/M2 23.6in 92PPI Square Tft Display M238HCA-L3B Innolux
250cd/M2 23.6in 92PPI Square Tft Display M238HCA-L3B Innolux 250cd/M2 23.6in 92PPI Square Tft Display M238HCA-L3B Innolux 250cd/M2 23.6in 92PPI Square Tft Display M238HCA-L3B Innolux 250cd/M2 23.6in 92PPI Square Tft Display M238HCA-L3B Innolux 250cd/M2 23.6in 92PPI Square Tft Display M238HCA-L3B Innolux

Large Image :  250cd/M2 23.6in 92PPI Square Tft Display M238HCA-L3B Innolux

Product Details:
Place of Origin: JAPAN
Brand Name: INNOLUX
Certification: ISO9001
Model Number: M238HCA-L3B
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 1000PCS
Contact Now

250cd/M2 23.6in 92PPI Square Tft Display M238HCA-L3B Innolux

Description
MODEL NUMBER: M238HCA-L3B BRAND: INNOLUX
SIZE: 23.6 Inch BRIGHTNESS: 250CD/M2
Lamp Type: WLED RESOLUTION: 1920(RGB)×1080, FHD, 92PPI
VIEWING ANGLEG: 89/89/89/89 (Typ.)(CR≥10) TEMPERATURE RANGE: Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
High Light:

92PPI Square Tft Display

,

23.6in Square Tft Display

,

M238HCA-L3B

Innolux M238HCA-L3B Application Details

Basic Information :
Brand

M238HCA-L3BModel
Type
a-Si TFT-LCD , LCM
Used For

23.8 inchScreen Size
Alias
-
Environment :
Storage Temp.
-20 ~ 60 °C
Operating Temp.
0 ~ 50 °C
RoHS

1.5G (14.7 m/s²)Vibration



Innolux M238HCA-L3B Mechanical Details

Pixel Features :
Resolution
1920(RGB)×1080, FHD
Dot Pitch(mm)
0.0915×0.2745 (H×V)
Pixel Format
RGB Vertical Stripe
Pixel Pitch(mm)
0.2745×0.2745 (H×V) [92PPI]
Mechanical Size :
Active Area(mm)
527.04(H) × 296.46(V)
Bezel Area(mm)
-
Outline Dim.(mm)
535(H) × 313(V)
Depth(mm)
8.7/13.2 (Typ./Max.)
Outline Features :
Form Style
Flat Rectangle
Shape Style
3-side borderless
Aspect Ratio
16:9 (H:V)
Orientation
Landscape type
Mounting :
Rear mounting holes (15-M3)
Other Spec :
Weight
2.04/2.27/2.38Kgs (Min./Typ./Max.)
Treatment
Antiglare (Haze 25%), Hard coating (3H)



Innolux M238HCA-L3B Optical Details

Basic Information :
Luminance(cd/m²)
250 (Typ.)
Contrast Ratio
1000:1 (Typ.) (Transmissive)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Display Mode
AAS, Normally Black, Transmissive
Best View on
Symmetry
Response(ms)
8/7 (Typ.)(Tr/Td)
Color Performance :
White Coordinate
Wx:0.313; Wy:0.329
Display Colors
16.7M (8-bit)
Color Temperature
6485K
White Uniformity
1.33 (Max.)(9 points)

1931 Color Gamlt :
NTSC Ratio
71%
sRGB
92% coverage
Adobe RGB
71% coverage
DCI-P3
74% coverage
Rec.2020
53% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



Innolux M238HCA-L3B Interface Detail

Signal Electrical :
Voltage Supply
5.0V (Typ.)
Current Supply
0.55/0.64A (Typ./Max.)
Signal Type :
LVDS (2 ch, 8-bit)
Logic Voltage
-
Interface Features :
Position

ConnectorType
Interface Detail :
Brand
Model
Pitch
Pins
Quantity
Pin Configuration
FOXCONN
GS23301-0321R-7H
1.0 mm
30 pins
1 pcs




Innolux M238HCA-L3B Backlight Details

Backlight Features :
Type
WLED
Quantity
-
Position
Edge light type
Replacement
-
Shape
4 strings
Life Time
40K(Min.) (Hours)
Lamp Electrical :
Voltage Supply
25.9/29/32V (Min./Typ./Max.)
Current Supply
100±5mA
Consumption
11.6/12.8W (Typ./Max.)
Interface Features :
Position

ConnectorType
Interface Detail :
Brand
Model
Pitch
Pins
Quantity
Pin Configuration
CviLux
CI1406M1VL0-NH
1.0 mm
6 pins
1 pcs
BLE-6PINS-CCAACC
Backlight Driver :
No





Innolux M238HCA-L3B Packing Details

Package Box : Quantity Weight Box Size
11 pcs / box 27 Kgs 620×348×430 mm (L×W×H)



 FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
