Product Details:
|
| Model Name: | LQ084V1DG44 | Manufacturer: | Sharp |
|---|---|---|---|
| Pixel Number: | 640(RGB)×480 (VGA) 95PPI | Screen Size: | 8.4 Inch |
| Screen Type: | LCM , A-Si TFT-LCD | Arrangement: | RGB Vertical Stripe |
| Backlight: | WLED | Signal Type: | Parallel RGB (1 Ch, 6-bit) Connector |
| High Light: | CCFL LVDS Industrial LCD Panel,CCFL NEC TFT Panel |
||
LQ084 Series LQ084V1DG44 LQ084V1DG43 LQ084V1DG42 LQ084V1DG41
| Basic Information : | Brand | Model | LQ084V1DG44 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 8.4" | Alias | - |
| Pixel Features : | Resolution | 640(RGB)×480, VGA | Dot Pitch(mm) | 0.089×0.267 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.267×0.267 (H×V) [95PPI] | |
| Mechanical Size : | Active Area(mm) | 170.88(H) × 128.16(V) | Bezel Area(mm) | 175.9(H) × 134.6(V) |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 4:3 (H:V) | Orientation | Landscape type |
| Basic Information : | Brand | Model | Type | Model Alias |
|---|---|---|---|---|
| LQ084V1DG44 | a-Si TFT-LCD , LCM |
| Interface Features : | Position | Type | Interface | |||
|---|---|---|---|---|---|---|
| - | Connector | Parallel RGB (1 ch, 6-bit) | ||||
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 170.88(W)×128.16(H) mm, viewing area size of 175.9(W)×134.6(H) mm. As a TN, Normally White, Transmissive LCM product, LQ084V1DG44 can provides . Gray scale or the brightness of the sub-pixel is determined with a 6-bit gray scale signal for each dot, thus presenting a palette of 262K colors. This product adopted WLED as it's backlight systerm which was placed as Edge light type (Top side). LQ084V1DG44 utilizes Parallel RGB (1 ch, 6-bit) as it's signal inputting systerm Connector. For more latest product detail of LQ084V1DG44 we strongly recommend that you should refer to datasheet listed on Panelook.com or contact with Sharp
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
