Product Details:
|
| MODEL NUMBER: | AT050TN33 V.1 | BRAND: | INNOLUX |
|---|---|---|---|
| SIZE: | 5.0 Inch | RESOLUTION: | 480(RGB)×272 (WQVGA) 109PPI |
| BRIGHTNESS: | 350CD/M2 | Lamp Type: | WLED |
| VIEWING ANGLEG: | 70/70/50/70 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| High Light: | WVGA Industrial TFT Display,NTSC Lcd Video Panel |
||
| Basic Information : | Luminance | 350 cd/m² (Typ.) | Contrast Ratio | 500 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | 6 o'clock | Response Speed | 10/15 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.310; Wy:0.330 | Support Color | 16.7M (8-bit) |
| Color Temperature | 6638K | White Uniformity | 1.33/1.43 (Typ./Max.)(9 points) |
| Pixel Features : | Number of Pixel | 480(RGB)×272 [WQVGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.077×0.231 mm | Pixel Pitch(W×H) | 0.231×0.231 mm [109PPI] | |
| Physical Size : | Active Viewing | 110.88(W)×62.832(H) mm | Overall Dim. | 120.7(W)×75.8(H) mm |
| Bezel Opening | 113.90(W)×65.85(H) mm | Overall Depth | 3.1±0.2 mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 16:9 | Shape Style | ||
| Other Detail : | Mass | 65.0g (Typ.) | Surface | Antiglare |
| Reverse Scan : | No |
|---|---|
| Power Consumption : | 855mW (Typ.) |
| Time Controller (T-CON) : | Embedded T-CON |
| Signal Electrical : | Input Current | 19/25mA (Typ./Max.) | Input Voltage | 3.3V (Typ.) | ||
|---|---|---|---|---|---|---|
| Consumption | 63mW (Typ.) | Signal Interface | Parallel RGB (1 ch, 8-bit) | |||
| Logic Voltage for Signals : | GND≤VIL≤0.2VDD; 0.8VDD≤VIH≤VDD | |||||
| Interface Features : | Position | - | Physical Type | FPC | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| 1 pcs | 0.5 mm | 40 pins | DRGB-40P1C8B-085A | |||
| Lamp Features: | Lamp Shape | Array | Lamp Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Exchange | - | Amount | 6S2P | Life | 20K(Min.) (Hours) | |
| Lamp Electrical : | Input Current | 40±4mA | Input Voltage | 19.8±1.2V | ||
| Consumption | 792mW (Typ.) | |||||
| Interface Features : | Position | - | Physical Type | Included in panel signal interface | ||
| Backlight Driver : | No | |||||
| Package Box : | Amount | Size (L×W×H) | Weight |
|---|
| : | ||||
|---|---|---|---|---|
