Product Details:
|
| MODEL NUMBER: | TM050QDH15 | BRAND: | TIANMA |
|---|---|---|---|
| SIZE: | 5.0 Inch | RESOLUTION: | 640(RGB)×480, VGA, 160PPI |
| Lamp Type: | WLED | TEMPERATURE RANGE: | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| SIGNAL LNTERFACE: | LVDS | ||
| High Light: | WLED Backlight Tianma TFT,WQVGA TIANMA LCD Panel |
||
| Basic Detail : | Manufacturer | Model Name | TM050QDH15 | |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 5.0 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | -20 ~ 70 °C | ST Temperature | -30 ~ 80 °C |
| Basic Information : | Luminance | - | Contrast Ratio | 500 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | - | Response Speed | - | |
| Viewing Angle | - | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | - | Support Color | 16.7M (6-bit + Dithering) |
| Pixel Features : | Number of Pixel | 640(RGB)×480 [VGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.0529×0.1587 mm | Pixel Pitch(W×H) | 0.1587×0.1587 mm [160PPI] | |
| Physical Size : | Active Viewing | 101.568(W)×76.176(H) mm | Overall Dim. | - |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 4:3 | Shape Style |
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 101.568(W)×76.176(H) mm. As a TN, Normally White, Transmissive LCM product, TM050QDH15 can provides 500:1 transimissive contrast ratio . Gray scale or the brightness of the sub-pixel is determined with a 6-bit + Dithering gray scale signal for each dot, thus presenting a palette of 16.7M colors. This product adopted WLED as it's backlight systerm which was placed as Edge light type. For more latest product detail of TM050QDH15 We strongly recommend that you should refer to datasheet listed on Panelook.com or contact with TIANMA or it's distributor. The above parameters are not from the datasheet, only as a reference, please use with caution!
