TX23D203VM0BPA KOE 9.0" 800(RGB)×480 900 cd/m² Storage Temp.: -30 ~80 °C INDUSTRIAL LCD DISPLAY

TX23D203VM0BPA KOE 9.0" 800(RGB)×480 900 cd/m²  Storage Temp.: -30 ~80 °C INDUSTRIAL LCD DISPLAY
TX23D203VM0BPA KOE 9.0" 800(RGB)×480 900 cd/m²  Storage Temp.: -30 ~80 °C INDUSTRIAL LCD DISPLAY TX23D203VM0BPA KOE 9.0" 800(RGB)×480 900 cd/m²  Storage Temp.: -30 ~80 °C INDUSTRIAL LCD DISPLAY TX23D203VM0BPA KOE 9.0" 800(RGB)×480 900 cd/m²  Storage Temp.: -30 ~80 °C INDUSTRIAL LCD DISPLAY

Large Image :  TX23D203VM0BPA KOE 9.0" 800(RGB)×480 900 cd/m² Storage Temp.: -30 ~80 °C INDUSTRIAL LCD DISPLAY

Product Details:
Place of Origin: JAPAN
Brand Name: KOE
Certification: ISO9001
Model Number: TX23D203VM0BPA
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 200PCS

TX23D203VM0BPA KOE 9.0" 800(RGB)×480 900 cd/m² Storage Temp.: -30 ~80 °C INDUSTRIAL LCD DISPLAY

Description
MODEL NUMBER: TX23D203VM0BPA BRAND: KOE
SIZE: 9.0"inch RESOLUTION: 800(RGB)×480 [WVGA] 103PPI
BRIGHTNESS: 900 Cd/m² (Typ.) TEMPERATURE RANGE: Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 M/s²)
High Light:

TFT LCD Panel LVDS

,

LVDS TFT LCD Module

,

VGA Touch Lcd Video Display

KOE TX23D203VM0BPA Application Details

Basic Detail : Manufacturer   Model Name TX23D203VM0BPA
Panel Type a-Si TFT-LCD , LCM Another Name -
Panel Size 9.0 inch Designed For



Maximum Ratings : OP Temperature -20 ~ 70 °C ST Temperature -30 ~ 80 °C
Vibration Level 2.0G (19.6 m/s²)



KOE TX23D203VM0BPA Optical Details

Basic Information : Luminance 900 cd/m² (Typ.) Contrast Ratio 1000 : 1 (Typ.) (Transmissive)
Good View at Symmetry Response Speed 40 (Typ.)(Tr+Td) (ms)
Viewing Angle 85/85/85/85 (Typ.)(CR≥10)  Operating Mode IPS, Normally Black, Transmissive
Color Performance : Chromaticity Wx:0.300; Wy:0.320 Support Color 262K/16.7M (6-bit / 8-bit)
Color Temperature 7351K White Uniformity 1.33 (Max.)(9 points)
1931 Color Gamut : NTSC Ratio 72% sRGB 93% coverage
Adobe RGB 72% coverage DCI-P3 75% coverage
Rec.2020 54% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance : Outdoor Visibility Sunlight Readable Transmissivity



KOE TX23D203VM0BPA Mechanical Details

Pixel Features : Number of Pixel 800(RGB)×480 [WVGA] Arrangement RGB Vertical Stripe
Dot Pitch(W×H) 0.082×0.246 mm Pixel Pitch(W×H) 0.246×0.246 mm [103PPI]
Physical Size : Active Viewing 196.8(W)×118.08(H) mm Overall Dim. 218(W)×135(H) mm
Bezel Opening 200(W)×121.28(H) mm Overall Depth 12.65±0.5 mm
Outline Features : Form Shape Flat Rectangle Orientation Landscape type
Aspect Ratio(W:H) 15:9 Shape Style
Touchscreen : TP Controller Without controller Control Signal -
Touch Points - TP Technology 4-wire Resistive Touch
Fixation : Rear mounting holes (4-M3)
Other Detail : Mass 415g (Typ.) Surface Hard coating (3H)






KOE TX23D203VM0BPA Electronics Details

Refresh Rate : 60Hz
Reverse Scan : Yes (180°)





KOE TX23D203VM0BPA Interface Details

Signal Electrical : Input Current 330/370/430mA (Min./Typ./Max.) Input Voltage 3.3V (Typ.)
Consumption 1.2W (Typ.) Signal Interface LVDS (1 ch, 6/8-bit)
Interface Features : Position - Physical Type Connector
Signal Interface : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
JAE FI-SEB20P-HF13E 1 pcs 1.25 mm 20 pins



KOE TX23D203VM0BPA Lightting Details

Lamp Features: Lamp Shape - Lamp Type WLED Position Edge light type
Exchange - Amount - Life 70K(Typ.) (Hours)
Interface Features : Position - Physical Type Connector
Interface Detail : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
JST SM08B-SRSS-TB 1 pcs 1.0 mm 8 pins
Backlight Driver : With LED Driver
Driver Electrical : Input Current 400±40mA Input Voltage 12.0±0.5V
Consumption 4.8W (Typ.)



whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 196.8(W)×118.08(H) mm, outline size of 218(W)×135(H)×13.15(D) mm, viewing area size of 200(W)×121.28(H) mm, with surface treament of Hard coating (3H), net weight of 415g (Typ.). As a IPS, Normally Black, Transmissive LCM product, TX23D203VM0BPA can provides 900 cd/m² display brightness 1000:1 transimissive contrast ratio, 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 40 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit / 8-bit gray scale signal for each dot, thus presenting a palette of 262K/16.7M colors, also with performance of color gamut 72% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 70K hours, With LED Driver. TX23D203VM0BPA utilizes LVDS (1 ch, 6/8-bit) as it's signal inputting systerm, which connected by 20 pins Connector with power supply voltage of 3.3V (Typ.
