TX23D200VM0BAA KOE 9.0" 800(RGB)×480 500 cd/m² Storage Temp.: -40 ~90 °C INDUSTRIAL LCD DISPLAY

Large Image : TX23D200VM0BAA KOE 9.0" 800(RGB)×480 500 cd/m² Storage Temp.: -40 ~90 °C INDUSTRIAL LCD DISPLAY

Product Details:

Place of Origin:	JAPAN
Brand Name:	KOE
Certification:	ISO9001
Model Number:	TX23D200VM0BAA

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Packaging Details:	STANDARD PACKING
Delivery Time:	1-2 DAYS
Payment Terms:	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability:	600PCS

Contact Now

TX23D200VM0BAA KOE 9.0" 800(RGB)×480 500 cd/m² Storage Temp.: -40 ~90 °C INDUSTRIAL LCD DISPLAY

Description

MODEL NUMBER:	TX23D200VM0BAA	BRAND:	KOE
SIZE:	9.0INCH	RESOLUTION:	800(RGB)×480 [WVGA] 133PPI
BRIGHTNESS:	500CD/M2	TEMPERATURE RANGE:	Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 80 °C ; Vibration Level: 5.0G (49.0 M/s²)
High Light:	TFT LCD Panel LVDS , LVDS TFT LCD Module , VGA Touch Lcd Video Display

KOE TX23D200VM0BAA Application Details

Basic Info :	Panel Brand Panel Model TX23D200VM0BAA Diagonal Size 9.0" Application Panel Type a-Si TFT-LCD , LCM Model Alias -
Reliability :	Operating Temp. -30 ~ 80 °C Storage Temp. -40 ~ 90 °C RoHS State Vibration Rating 5.0G (49.0 m/s²)
Specific Features :
Remarks :	Rugged+, B-G-R sub-pixel structure

KOE TX23D200VM0BAA Mechanical Details

Pixel Features :	Pixel Format 800(RGB)×480, WVGA Dot Pitch 0.082×0.246 mm (H×V) Configuration RGB Vertical Stripe Pixel Pitch 0.246×0.246 mm (H×V) [103PPI]
Mechanical Size :	Display Area 196.8×118.08 mm (H×V) Bezel Area - Outline Dim. 218×135 mm (H×V) Outline Depth 11.15 (Typ.) mm
Outline Features :	Form Factor Flat Rectangle Orientation Landscape type Aspect Ratio 15:9 (H:V) Shape Style
Holes & Brackets :	Rear mounting holes (4-Φ2.88)
Other Features :	Weight 330g (Typ.) Surface

KOE TX23D200VM0BAA Mechanical Details

Pixel Features :	Pixel Format 800(RGB)×480, WVGA Dot Pitch 0.082×0.246 mm (H×V) Configuration RGB Vertical Stripe Pixel Pitch 0.246×0.246 mm (H×V) [103PPI]
Mechanical Size :	Display Area 196.8×118.08 mm (H×V) Bezel Area - Outline Dim. 218×135 mm (H×V) Outline Depth 11.15 (Typ.) mm
Outline Features :	Form Factor Flat Rectangle Orientation Landscape type Aspect Ratio 15:9 (H:V) Shape Style
Holes & Brackets :	Rear mounting holes (4-Φ2.88)
Other Features :	Weight 330g (Typ.) Surface

KOE TX23D200VM0BAA Optical Details

Basic Information :	Brightness 500 cd/m² (Typ.) Contrast Ratio 800:1 (Typ.) (Transmissive) Viewing Angle 85/85/85/85 (Typ.)(CR≥10) Optical Mode IPS, Normally Black, Transmissive Viewing Direction Symmetry Response Time 40 (Typ.)(Tr+Td) ms
Color Performance :	Chromaticity Wx:0.320; Wy:0.310 Color Numbers 16.7M (6-bit + Hi-FRC) Color Temperature 6239K Uniformity 1.33 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio 56% sRGB 77% coverage Adobe RGB 58% coverage DCI-P3 58% coverage Rec.2020 42% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

KOE TX23D200VM0BAA Electronics Details

Frame Frequency :	60Hz Reverse Scan :	No

KOE TX23D200VM0BAA Backlight Details

Back-light Features :	Lamp Type WLED Amount 7S3P Life Time 70K(Typ.) (Hours) Replacement - Lamp Shape - Position Edge light type
Interface Features :	Type Connector Position - Lamp Driver With LED Driver
Interface Detail :	Brand Model Pin Pitch Pins Amount Configuration JST SM08B-SRSS-TB 1.0 mm 8 pins 1 pcs BDE-8PINS-VVVNNGGG
Driver Electrical :	Voltage Input 12.0V (Typ.) Current Input 370±40mA Consumption 4.4W (Typ.)

KOE TX23D200VM0BAA Interface Detail

Signal Systerm :	LVDS (1 ch, 8-bit) Logic Voltage -
Signal Electrical :	Voltage Input 3.3V (Typ.) Current Input 430/560mA (Typ./Max.) Consumption 1.4W (Typ.)
Interface Features :	Type Connector Position -
Connector Detail :	Brand Model Pin Pitch Pins Amount Configuration JAE FI-SEB20P-HF13E 1.25 mm 20 pins 1 pcs
