Product Details:
|
| MODEL NUMBER: | TX18D38VM0EAA | BRAND: | HITACHI |
|---|---|---|---|
| SIZE: | 7.0INCH | RESOLUTION: | 1024(RGB)×600, WSVGA, 169PPI |
| BRIGHTNESS: | 400 Cd/m² (Typ.) | TEMPERATURE RANGE: | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C ; Vibration Level: 5.0G (49.0 M/s²) |
| SIGNAL LNTERFACE: | LVDS | Lamp Type: | WLED |
| High Light: | TFT LCD Panel LVDS,LVDS TFT LCD Module,VGA Touch Lcd Video Display |
||
| Basic Information : | Brand |  |
Model | TX18D38VM0EAA |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For |
|
|
| Screen Size | 7.0" | Alias | - | |
| Environment : | Storage Temp. | -30 ~~ 70 °C | Operating Temp. | -10 ~~ 60 °C |
| RoHS | |
Vibration | 5.0G (49.0 m/s²) | |
| Typical Features : |
|
|||
| Pixel Features : | Resolution | 1024(RGB)×600, WSVGA | Dot Pitch(mm) | 0.050×0.150 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.150×0.150 (H×V) [169PPI] | |
| Mechanical Size : | Active Area(mm) | 153.6(H) × 90(V) | Bezel Area(mm) | 156.1(H) × 92.5(V) |
| Outline Dim.(mm) | 162.8(H) × 103.1(V) | Depth(mm) | 2.71/4.5 (Typ./Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 17:10 (H:V) | Orientation | Landscape type | |
| Mounting : | Face mounting holes (2-Φ3.0, 2-R1.5) on up, down slugs | |||
| Other Spec : | Weight | 90.0g (Typ.) | Treatment | Antiglare |
| Basic Information : | Luminance(cd/m²) | 400 (Typ.) | Contrast Ratio | 800:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
Display Mode | IPS, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 35 (Typ.)(Tr+Td) | |
| Color Performance : | White Coordinate | X:0.310; Y:0.330 | Display Colors | 16.7M (8-bit) |
| Color Temperature | 6638K | White Uniformity | 1.18/1.25 (Typ./Max.)(9 points) |
|
| 1931 Color Gamlt : | NTSC Ratio | 52% | sRGB | 72% coverage |
| Adobe RGB | 54% coverage | DCI-P3 | 54% coverage | |
| Rec.2020 | 39% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Frame Rate : | 60Hz Reverse Scan :
| No |
|---|---|---|
| Power Consumption : | 1.80W (Typ.) |
| Signal Electrical : | Voltage Supply | 3.3V (Typ.) | Current Supply | - | ||
|---|---|---|---|---|---|---|
| Signal Type : | LVDS (1 ch, 8-bit) + SPI | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | FPC | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| 1 pcs | 30 pins | 0.5 mm | ||||
| Backlight Features: | Shape | 3 strings | Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | 7S3P | Life Time | 40K(Typ.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 22V (Typ.) | Current Supply | 41.1mA (Typ.) | ||
| Interface Features : | Position | - | Type | Included in panel signal interface | ||
| Backlight Driver : | No | |||||
