Product Details:
|
| AA121SP08 Mitsubishi12.1%22 800(RGB)×600 400 Cd/m² INDUSTRIAL LOD DISPLAY: | AA121SP08 | BRAND: | Mitsubishi |
|---|---|---|---|
| SIZE: | 12.1 Inch | RESOLUTION: | 800(RGB)×600, SVGA, 82PPI |
| BRIGHTNESS: | 400 Cd/m² (Typ.) | Lamp Type: | WLED |
| SIGNAL LNTERFACE: | LVDS | ||
| High Light: | TFT LCD Display SVGA 119PPI,LVDS TFT LCD Module |
||
The AA121SP08 is a 12.1 inch diagonal a-Si TFT-LCD display panel product from Mitsubishi Electric Corporation (hereafter called Mitsubishi), with an integral CCFL backlight system, without touch screen. It's general features are summarized by Panelook in the following: Lamp Repaceable, Life ≥ 50K hours, 180° Reverse, 6/8 bit . Based on its features, Panelook recommend that this model be applied to Industrial etc. Now this model is discontinued. There are 0 items stock and 0 suppliers of this model on Panelook. We inputted this model's specification on Dec 31 2011 for the first time. If you want to embed AA121SP08 LCM in your future product, Panelook strongly recommend that you should contact with Mitsubishi or it's agent to learn lateast production and specification detail. The AA121SP08 production status marked on Panelook.com is for reference only and should not be used as the basis for the user's decision making. The above parameters are not from the datasheet, only as a reference, please use with caution!
| Basic Detail : | Manufacturer |  |
Model Name | AA121SP08 |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 12.1 inch | Designed For |
|
|
| Maximum Ratings : | OP Temperature | - | ST Temperature | - |
| Vibration Level | - | RoHS | |
|
| Features : |
|
|||
| Basic Information : | Luminance | 400 cd/m² (Typ.) | Contrast Ratio | 500 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | 6 o'clock | Response Speed | - | |
| Viewing Angle | 80/80/70/80 (Typ.)(CR≥10) |
Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | - | Support Color | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| Pixel Features : | Number of Pixel | 800(RGB)×600 [SVGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.1025×0.3075 mm | Pixel Pitch(W×H) | 0.3075×0.3075 mm [82PPI] | |
| Physical Size : | Active Viewing | 246(W)×184.5(H) mm | Overall Dim. | 280(W)×210(H) mm |
| Bezel Opening | - | Overall Depth | 12.0 (Typ.) mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 4:3 | Shape Style | ||
| Other Detail : | Mass | 770g (Typ.) | Surface | - |
